The KTM 350 EXC-F WESS Enduro is a formidable force on the track, engineered to dominate the WESS Enduro World Championship’s diverse and demanding terrain. Its four-stroke, single-cylinder engine delivers a perfect blend of power and response, catering to a wide range of rider skills and preferences.

The WP XACT air fork technology, first applied to a KTM Enduro model, brings works-level suspension to the masses, while exclusive upgrades such as factory wheels, a radiator fan, and CNC-machined triple clamps further enhance the bike’s performance and style.

Built on the highly acclaimed KTM 350 EXC-F platform, this special model combines the agility of a smaller-cylinder machine with the power and torque of a larger bike, making it an incredibly versatile and desirable solution for off-road enthusiasts of all ages and backgrounds.

The result is a machine that’s as at home on fast trails as it is on technical obstacles, and its advanced DOHC engine, weighing in at under 28 kg, works in perfect harmony with the state-of-the-art chromoly steel frame to deliver a balance of power and handling that’s hard to beat.

Key Specifications

Engine TypeFour stroke, single cylinder, DOHC with finger followers, 4 valves per cylinde
Engine Capacity349.7 cc / 21.3 cu in
Fuel Tank Capacity2.3 US gallons / 9.0 L
Seat Height37.7 inches / 960 mm
KTM 350 EXC-F WESS Enduro (2021)

All Specifications

Make & Model

ModelKTM 350 EXC-F WESS Enduro
Year2021

Engine

Engine TypeFour stroke, single cylinder, DOHC with finger followers, 4 valves per cylinde
Displacement349.7 cc / 21.3 cu in
Bore x Stroke88 x 57.5 mm
Compression Ratio12.3:1
Engine Management SystemKeihin EFI, flow restrictor 42 mm
Lubrication SystemTwin oil pumps
Cooling SystemLiquid cooled

Performance

Top Speedn/a

Transmission

ClutchWet, DDS multi-disc clutch, Brembo hydraulics
Gearbox6Speed
Secondary Drive Ratio14:52
Gear Ratios1st 14:32 / 2nd 16:26 / 3rd 20:25 / 4th 22:23 / 5th 25:22 / 6th 26:20
Final DriveChain, X-Ring 5/8 x 1/4″

Electrical & Electronics System

BatteryYTX4L-BS, 12V 3Ah, maintenance free
StarterElectric

Chassis & Suspension

Frame TypeChrome-molybdenum steel central-tube frame
Front Suspension48mm WPXACT-USDforks
Front Suspension Travel11.8 inches / 300 mm
Rear SuspensionWP Xplor PDS shock absorber
Rear Suspension Travel12.2 inches / 310 mm
Trail63.5

Wheels & Brakes

Front Tire Size90/90 – 21 M/C 54M M+S TT
Rear Tire Size140/80 – 18 M/C 70M M+S TT
Front BrakesSingle 260 mm disc, 2 piston caliper
Rear BrakesSingle 220 mm disc, 1 piston caliper

Dimension & Weights

Seat Height37.7 inches / 960 mm
Wheelbase58.3 inches / 1482 mm
Ground Clearance355 mm / 13.9 in
Fuel Tank Capacity2.3 US gallons / 9.0 L
Dry Weight104 kg / 229 lbs

Features

  • Four-stroke, single cylinder engine
  • DOHC with finger followers, 4 valves per cylinder
  • WP XACT air fork technology
  • 48 mm air fork
  • Easy-access clickers for damping
  • Air pressure valve for preload
  • Factory wheels with anodized hubs
  • Radiator fan and protectors
  • Racing seat
  • Supersprox stealth rear sprocket
  • Map select switch
  • Rear brake safety wiring
  • CNC machined triple clamps
  • 350 cc fuel-injected DOHC engine
  • Chromoly steel frame
  • Plastic skid plate
  • Grippy Factory seat
  • Factory READY TO RACE set-up
