The KTM 300 EXC is a high-performance two-stroke enduro bike that has been a favorite among Australian dirt riders for years. Its potent engine and agile handling make it a joy to ride on both trails and tracks. The 300 EXC has evolved over time to meet the growing demand for more race-oriented bikes, with notable improvements including chain adjustment marks on the swingarm and a well-designed package overall.
The bike’s engine is a powerhouse, delivering quick acceleration and nimble handling that makes it a thrill to ride. The adjustable handlebars provide a comfortable riding position, while the highly maneuverable chassis allows for precise control on tight trails. The 300 EXC’s braking system is also impressive, providing confident stopping power when needed.
The KTM 300 EXC is a true classic in the world of enduro bikes, offering a unique blend of power, agility, and versatility that is hard to match. With its lightweight design, impressive engine performance, and well-designed features, this bike is a must-ride for any serious off-road enthusiast.
Key Specifications
Engine Type
Two stroke, single cylinder
Engine Capacity
297 cc / 18.1 cu in
Fuel Tank Capacity
8.5L / 2.2 US gal / 1.9 Imp gal
Seat Height
37.2 inches / 945 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM 300 EXC Enduro
Year
2001 – 2002
Engine
Engine Type
Two stroke, single cylinder
Displacement
297 cc / 18.1 cu in
Bore x Stroke
72 x 72 mm
Compression Ratio
11.0:1
Engine Management System
Keihin PWK36 S AG carburetor
Cooling System
Liquid cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet, multi-plate, hydraulically operated
Gearbox
5 Speed
Final Drive
Chain, Regina O-ring
Electrical & Electronics System
Starter
Kick
Chassis & Suspension
Frame Type
Central double cradle, CrMo4
Front Suspension
WP48 mm upside down fork and shock
Rear Suspension
Fully adjustable WP-PDSmono-shock
Trail
62.5o
Wheels & Brakes
Front Tire Size
90/90 – 21, Michelin MP11
Rear Tire Size
140/80 – 18
Front Brakes
Single260 mm disc, 2 piston caliper
Rear Brakes
Single 220 mm disc, 1 piston caliper
Dimension & Weights
Seat Height
37.2 inches / 945 mm
Wheelbase
58.1 inches / 1476 mm
Ground Clearance
386 mm / 15.2 in
Fuel Tank Capacity
8.5L / 2.2 US gal / 1.9 Imp gal
Dry Weight
103 kg / 227 lbs
Features
Slim and lightweight design
Highly maneuverable
Fast enough to get attention
Adjustable handlebars
Non-tapered handlebars
Functional instrument pack
Easy-to-read instrument pack
Upper speed limit of 180km/h
Well-designed switchgear
Small switchgear
Tiny blinkers
No-linkage shock setup
Low maintenance shock setup
WP suspension
Adjustable PDS shock
Plush and progressive fork
Reduced sensitivity to ride height settings
Good performance over rough terrain at high speed
