The KTM 300 EXC Enduro is a formidable off-road machine, engineered to conquer the toughest terrain with its compact, light, and powerful single-cylinder two-stroke engine. This engine is the heart of the EXC, providing the raw power and agility needed to navigate difficult off-road conditions. But it’s not just about the engine – the EXC’s suspension is equally impressive, featuring high-spec WP upside-down forks and a rear monoshock that can withstand even the most demanding off-road use.
The 300 EXC’s setup is a masterclass in balance and control, with a chassis designed to work in harmony with its suspension. Our testing revealed that with the right settings and tires, the EXC can excel in a variety of off-road environments, from the mud of Delaware to the sand of other tracks. With its potent engine and exceptional suspension, the KTM 300 EXC Enduro is a force to be reckoned with, capable of dominating even the most challenging off-road courses.
Key Specifications
Engine Type
Two stroke, single cylinder
Engine Capacity
297 cc / 18.1 cu in
Fuel Tank Capacity
13 L / 3.4 US gal / 2.9 Imp gal
Seat Height
37.2 inches / 945 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM 300 EXC Enduro
Year
1995 – 96
Engine
Engine Type
Two stroke, single cylinder
Displacement
297 cc / 18.1 cu in
Bore x Stroke
72 x 73 mm
Engine Management System
Keihin PWK38 D-slide carburetor
Cooling System
Liquid cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet, multi-plate
Gearbox
5 Speed
Final Drive
Chain, Regina O-ring
Electrical & Electronics System
Starter
Kick
Chassis & Suspension
Frame Type
Steel, CrMo
Front Suspension
Marzocchi 45 upside down fork and shock
Rear Suspension
Fully adjustable Ohlins 3Amono-shock
Trail
62.5o
Wheels & Brakes
Front Tire Size
90/90 – 21, Michelin MP11
Rear Tire Size
140/80 – 18
Front Brakes
Single260 mm disc
Rear Brakes
Single 220 mm disc
Dimension & Weights
Seat Height
37.2 inches / 945 mm
Wheelbase
58.3 inches / 1480 mm
Ground Clearance
385 mm / 15.2 in
Fuel Tank Capacity
13 L / 3.4 US gal / 2.9 Imp gal
Dry Weight
112 kg / 247 lbs
Features
Single-cylinder two-stroke engine
Compact and light design
Powerful engine for off-road use
WP upside-down forks
Rear monoshock suspension
Dedicated off-road tyres
Small headlight
Speedo
Tail-light
Keihin PWK 38 carby
Stock jetted with a 180 main, 48 pilot jet
Adjustable fork compression
Adjustable fork rebound
Adjustable shock compression
Adjustable shock rebound
Adjustable sag
Removable countershaft sprocket (13T or 14T)
