KTM 200 EXC Enduro (2009 – 2010)

KTM 200 EXC Enduro (2009 - 2010)

The 200 EXC Enduro is a game-changer, marrying the agility of a 125 with the raw power of a 250cc bike. This potent combination delivers an exhilarating riding experience, perfect for those who crave the ultimate edge on the trail. With its newly designed frame, borrowed from the 250SXF chassis, the 200 EXC boasts a lightweight yet robust construction, allowing for precise handling and razor-sharp agility.

The engine character is nothing short of exceptional, with a potent punch that belies its 200cc displacement. The bike’s responsiveness and throttle control are simply outstanding, making it an absolute joy to ride. Whether carving through tight singletrack or tackling demanding terrain, the 200 EXC Enduro proves itself to be a true thoroughbred, capable of handling even the most challenging conditions with ease.

The 200 EXC Enduro’s impressive power output, combined with its featherlight weight, makes it a formidable opponent on the trail. Its handling is nothing short of exceptional, with the bike seeming to shrink around the rider as it devours every twist and turn. The 200 EXC Enduro is the ultimate tool for the discerning off-road enthusiast, offering a unique blend of power, agility, and finesse that’s unmatched in its class. It’s a bike that truly lives up to its reputation as a champion of the trails.

Key Specifications

Engine TypeSingle cylinder, 2-stroke
Engine Capacity193 cc / 11.8 cu in
Fuel Tank Capacity9 L or 11 L / 2.4 US gal or 2.9 US gal / 2.0 Imp gal or 2.4 Imp gal
Seat Height36.4 inches / 925 mm
KTM 200 EXC Enduro (2009 - 2010)

All Specifications

Make & Model

ModelKTM 200 EXC Enduro
Year2009 – 2010

Engine

Engine TypeSingle cylinder, 2-stroke
Displacement193 cc / 11.8 cu in
Bore x Stroke64 x 60 mm
Compression Ratio12.5:1
Engine Management SystemKeihin PWK 38 AGI flat slide
Cooling SystemLiquid cooled

Performance

Top Speedn/a

Transmission

ClutchWet, multi-plate, hydraulically operated
Gearbox6 Speed
Primary Drive Ratio23/73
Gear Ratios1st 13:33 / 2nd 15:31 / 3rd 17:28 / 4th 19:26 / 5th 21:25 or 17:17 / 6th 20:20
Final DriveChain, 5/8 x 1/4″

Electrical & Electronics System

StarterKick

Chassis & Suspension

Frame TypeCentral chrome-moly-steel frame
Front SuspensionWP 48 mm upside down fork
Front Suspension Travel11.8 inches / 300 mm
Rear SuspensionWP Progressive Damping System shock absorber, aluminium swingarm
Trail63o

Wheels & Brakes

Front Tire Size90/90 – 21″ MT83
Rear Tire Size120/90 – 18″ M59
Front BrakesDisc brake with carbon-steel brake disc 260 mm (10.2 in), Brembo brake caliper floated
Rear BrakesDisc brake with carbon-steel brake disc 220 mm (8.7 in), Brembo brake caliper floated

Dimension & Weights

Seat Height36.4 inches / 925 mm
Wheelbase57.3 inches / 1461 mm
Ground Clearance390 mm / 15.3 in
Fuel Tank Capacity9 L or 11 L / 2.4 US gal or 2.9 US gal / 2.0 Imp gal or 2.4 Imp gal
Dry Weight97kg / 214 lbs

Features

  • New frame based on the 250SXF chassis
  • Chrome-moly tubing for the frame
  • New sub-frame
  • Swing-arm and shock from the race bike
  • Improved handling
  • Featherweight design
  • Fat graphics on the bike
  • Black anodised rims
  • Nickel-coated exhaust
  • Kick-starter well placed
  • Easy to start with a single kick
  • Electric start option
  • Smaller design than expected
  • Easy to handle and maneuver
  • 200cc engine
  • Powerful performance
  • All-new design for 2008 model
