KTM 1290 Super Duke GT (2022)

KTM 1290 Super Duke GT (2022)

The 2022 KTM 1290 Super Duke GT is a masterclass in contrasts, blending the raw power and agility of a Sports bike with the long-distance comfort and capability of a Grand Tourer. Its 175 HP, 141 Nm EURO 5-rated V-twin engine is a marvel, delivering instant torque and a thrilling riding experience that’s as at home on twisty mountain roads as it is on the open highway.

The KTM 1290 Super Duke GT’s WP APEX semi-active suspension is a game-changer for long-distance riders, offering intuitive preload adjustability and four distinct ride modes to suit any situation. Whether you’re solo, with a pillion, or loaded up with luggage, the bike adapts to your needs with ease. And with its sleek, premium switchgear and 7-inch TFT display, you’ll be able to adjust your ride on the fly with ease, always staying connected to the road. The result is a machine that’s equal parts thrill-seeker and comfortable companion, perfect for anyone who wants to ride far and ride free. It is the ultimate long-distance motorcycle experience.

Key Specifications

Engine Type75 V twin, 4 stroke, DOHC, 4 valve per cylinder, titanium inlet valves
Engine Capacity1301 cc / 79.4 cu in
Max Torque104 ft-lb / 141 nm
Fuel Tank Capacity6.1 US gallons / 23.0 L
Seat Height32.9 inches / 835 mm
KTM 1290 Super Duke GT (2022)

All Specifications

Make & Model

ModelKTM 1290 Super Duke GT
Year2022

Engine

Engine Type75 V twin, 4 stroke, DOHC, 4 valve per cylinder, titanium inlet valves
Displacement1301 cc / 79.4 cu in
Bore x Stroke108 x 71 mm
Max Torque104 ft-lb / 141 nm
Engine Management SystemKeihin EFI, throttle body 56 mm
Lubrication SystemPressure lubrication, 3 Eaton pumps
Cooling SystemLiquid cooling

Performance

Top Speedn/a

Transmission

ClutchPASC slipper, hydraulically operated
Gearbox6-Speed with up/down quickshifter
Final DriveChain

Electrical & Electronics System

StarterElectric
ABSBosch 9ME Combined ABS (incl. cornering ABS and supermoto mode, disengageable)

Chassis & Suspension

Frame TypeChrome-moly tubular space frame, powder-coated
Front SuspensionWP Semi-active suspension USD 48 mm
Front Suspension Travel4.9 inches / 125 mm
Rear SuspensionWP SAT (semi-active technology) shock absorber
Rear Suspension Travel6.1 inches / 156 mm
Rake24.9
Trail107 mm / 4.2 in

Wheels & Brakes

Front Wheel/Rim SizeAluminium, 3.50 x 17 in
Front Tire Size120/70 x 17, Pirelli Angel GT
Rear Wheel/Rim SizeAluminium, 6.00 x 17 in
Rear Tire Size190/55 x 17, Pirelli Angel GT
Front Brakes2x 320 mm discs, Brembo four-piston radial fixed calliper
Rear BrakesSingle 240 mm disc, Brembo twin-piston fixed calliper
ABSBosch 9ME Combined ABS (incl. cornering ABS and supermoto mode, disengageable)

Dimension & Weights

Seat Height32.9 inches / 835 mm
Wheelbase58.34 inches / 15 mm
Ground Clearance141 mm / 5.5 in
Fuel Tank Capacity6.1 US gallons / 23.0 L

Features

  • 75 V twin engine
  • 4 stroke, DOHC, 4 valve per cylinder
  • Titanium inlet valves
  • Keihin EMS with RBW and cruise control
  • Dual ignition
  • 2x 320 mm discs, Brembo four-piston radial fixed calliper
  • Single 240 mm disc, Brembo twin-piston fixed calliper
  • WP APEX semi-active suspension
  • Preload adjustability of the rear shock
  • Anti-dive function
  • 7 inch-TFT display
  • New robust switchgear
  • Wheels lifted from the latest KTM 1290 SUPER DUKE R
  • Weight saving of 1 kg of unsprung mass
  • Continental ContiSportAttack 4 tires
  • All-new navigation system called Turn-by-turn PLUS
  • Navigation instructions projected directly on the 7-inch TFT display
