The KTM 1290 Super Adventure S is the ultimate travel companion for the fearless and adventurous rider. Its 75-degree, V-twin engine is the epitome of power and versatility, delivering a rich, throaty exhaust note that’s as addictive as it is exhilarating.
With its advanced DOHC, 4-valve per cylinder design, this motor is capable of unleashing a wave of torque that’s simply irresistible. The result is a thrilling riding experience that’s as engaging as it is effortless, making it perfect for long-distance touring or conquering the most treacherous terrain.
The new 2023 model takes the rich heritage of the KTM 1290 Super Adventure S and adds a fresh coat of paint, including two stunning new color schemes: a bold orange-and-black trim or a more subdued gray aesthetic. But it’s not just about looks – the forged aluminum subframe has been engineered to offer improved load-carrying capability and a lower seat height, making it the perfect choice for riders who dare to venture further.
Key Specifications
Engine Type
Four stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Engine Capacity
79.3 cubic inches / 1301 cc
Max Power
118 kw / 160 hp
Max Torque
101.7 ft-lb / 138 nm
Fuel Tank Capacity
6 US gallons / 23.0 L
Seat Height
33.4 inches / 849 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM 1290 Super Adventure S
Year
2023
Engine
Engine Type
Four stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Displacement
79.3 cubic inches / 1301 cc
Bore x Stroke
108 x 71 mm
Compression Ratio
13.1:1
Max Horsepower
118 kw / 160 hp
Max Torque
101.7 ft-lb / 138 nm
Engine Management System
2x Keihin EFI, 52mm throttle bodies
Lubrication System
Forced oil lubrication with 3 oil pumps
Cooling System
Liquid cooling system, continuous circulation of cooling liquid with water pump
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
PASC anti-hopping clutch/ hydraulically operated
Gearbox
6-speed
Final Drive
Chain 525 X Ring
Electrical & Electronics System
Starter
Eletric
ABS
Bosch 10.3ME Combined-ABS (incl. Cornering-ABS and offroad mode)
Chassis & Suspension
Frame Type
Tubular space frame made from chrome molybdenum steel, powder-coated
Front Suspension
48 mm WP SAT (semi-active technology) Upside-Down forks
Front Suspension Travel
7.9 inches / 200 mm
Rear Suspension
WP SAT (semi-active technology) shock absorber
Rear Suspension Travel
7.9 inches / 200 mm
Trail
65.3
Wheels & Brakes
Front Tire Size
120/70-ZR19
Rear Tire Size
170/60-ZR17
Front Brakes
2 x 320 mm floating disc, Brembo four-piston brake calipers
Rear Brakes
Single 267 mm disc, Brembo two-piston brake caliper
ABS
Bosch 10.3ME Combined-ABS (incl. Cornering-ABS and offroad mode)
Dimension & Weights
Seat Height
33.4 inches / 849 mm
Wheelbase
62.2 inches / 1580 mm
Ground Clearance
223 mm / 8.7 in
Fuel Tank Capacity
6 US gallons / 23.0 L
Dry Weight
220 kg / 485 lbs
Features
75V-twin cylinder engine
DOHC with 4 valves per cylinder
160 hp power output
138 Nm of torque
7 TFT display
RIDE MODES
Advanced WP Semi-Active Suspension
ABS settings
Adaptive Cruise Control
Navigation plotting
Turn-by-Turn+ guidance
Waypoints markers
Audio tracks listing
Favorites for phone calls
Forged aluminum subframe
Lower seat height option
Load-carrying capability
Three-part 23-liter tank
Augmented navigation software
KTMConnect App integration
Infographics and menu system
