From the Skeleton Coast to the Himalayas, the KTM 1290 SUPER ADVENTURE R is engineered to cross the wildest, most challenging terrain with unmatched ability and class-leading performance. Not only has it proven itself to be without peers in the large-capacity extreme adventure segment, but it also remains the ultimate READY TO RACE choice in travel machines for hardened cross-country nomads.
Key Specifications
Engine Type
2-cylinder, 4-stroke, V 75° LC8
Engine Capacity
1301 cc
Max Power
160 HP / 119.3 Kw
Max Torque
138 Nm
Top Speed
~ 230 kmph / 142.9 mph
Fuel Tank Capacity
23 L / 6.07 US gallons
Weight (Wet/Kerb)
~ 245.25 kg / 540.68 lbs
Seat Height
880 mm / 34.64 inches
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM 1290 Super Adventure R (2024)
Year
2024 –
Engine
Engine Type
2-cylinder, 4-stroke, V 75° LC8
Displacement
1301 cc
Bore x Stroke
108 mm x 71 mm
Compression Ratio
13.1 : 1
Number of Cylinders
2
Max Horsepower
160 HP / 119.3 Kw
Max Torque
138 Nm
Valve Train
DOHC
Valves per Cylinder
4
Engine Management System
Keihin EMS with RBW and cruise control, double ignition
Cooling System
Liquid cooling, permanent circulation of coolant by water pump. 2 piece radiator
Ignition System
Electronic ignition
Fuel
Super Unleaded (ROZ 95)
Performance
Top Speed
~ 230 kmph / 142.9 mph
*n/a – information not provided by manufacturer
Transmission
Clutch
Multidisc Clutch in oil bath/hydraulically operated
