The KTM 125 Duke is a thrilling ride that embodies the spirit of youth and freedom. With its water-cooled, 4-stroke single cylinder engine, this bike delivers a punchy 15bhp, perfectly suited for riders with an A1 license. The power delivery is smooth, and the six-gear transmission is a delight to use, with no uncomfortable vibrations even at the top of the rev counter.
Built in partnership with Bajaj, the world’s third-largest motorcycle manufacturer, the 125 Duke is a testament to KTM’s commitment to quality and innovation. The bike’s suspension, inspired by the flagship models, features WP upside-down forks with a 43mm outer tube diameter, providing exceptional handling and stability.
Whether you’re a seasoned rider or just starting out, the 125 Duke is an exhilarating experience that will leave you grinning from ear to ear. With its supersport-inspired feel, this bike is an absolute blast to ride, and its steeper steering head angle and reduced fork stroke only add to its agility and responsiveness, making it an absolute joy to navigate corners and twisties.
Key Specifications
Engine Type
Four stroke, single cylinder, DOHC, 4 Valves
Engine Capacity
7.6 cubic inches / 124.7 cc
Max Power
11.3 kw / 15 hp
Max Torque
12 Nm / 1.22 kgf-m / 8.85 ft-lb @ 8000 rpm
Fuel Tank Capacity
2.9 US gallons / 11.0 L
Seat Height
31.8 inches / 810 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM 125 Duke
Year
2013 – 2014
Engine
Engine Type
Four stroke, single cylinder, DOHC, 4 Valves
Displacement
7.6 cubic inches / 124.7 cc
Bore x Stroke
58 x 47 mm
Compression Ratio
14.5:1
Max Horsepower
11.3 kw / 15 hp
Max Torque
12 Nm / 1.22 kgf-m / 8.85 ft-lb @ 8000 rpm
Engine Management System
Electronic fuel injection
Lubrication System
Forced oil lubrication with 1 Eaton pump
Cooling System
Liquid cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Multi-disc clutch, operated hydraulically
Gearbox
6 Speed
Final Drive
Chain 5/8 x 1/4″ X Ring
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Frame Type
Space frame in chrome -molybdenum steel tubes Subframe: steel
Front Suspension
38 mm WP upside-down fork
Front Suspension Travel
6.2 inches / 160 mm
Rear Suspension
WP monoshock.
Rear Suspension Travel
6.2 inches / 160 mm
Trail
65
Wheels & Brakes
Front Tire Size
110/70 -17
Rear Tire Size
150/60 -17
Front Brakes
Single 280 mm disc
Rear Brakes
Single 220 mm disc
Dimension & Weights
Seat Height
31.8 inches / 810 mm
Wheelbase
53.8 inches / 1367 mm
Ground Clearance
170 mm / 6.7 in
Fuel Tank Capacity
2.9 US gallons / 11.0 L
Dry Weight
127 kg / 280 lbs
Features
Water-cooled, 4-stroke single cylinder engine
15bhp power output
6-speed gearbox
Gear shift indicator
WP upside down (USD) forks
43mm outer tube diameter on forks
Stiffer spring inside fork for supersport feel
Reduced fork stroke to 125mm
Adjustable rear shock preload
150mm rear shock travel
Steepened steering head angle to 66.5
Shorter wheelbase
Four piston radially bolted caliper on front
Single piston caliper on rear
Bosch ABS as standard
LED indicators hidden in mirrors
Tail-light positioned under rear seat cowl
Orange wheel rims
Chunky 150mm rear tyre
Pillion seat made from rubber
