The KTM 1190 Adventure R – a motorcycle that embodies the raw, unbridled spirit of adventure. Its 75V-twin cylinder engine, with four valves per cylinder and DOHC, delivers a unique combination of power and character that’s both puristic and sportily challenging.
The addition of Bosch’s MSC (Motorcycle Stability Control) system takes the 1190 Adventure R to new heights of safety and control, featuring lean-sensitive traction control, ABS with a combined braking function, and the world’s first lean-sensitive cornering ABS. This enhanced package, combined with a further optimized chassis and longer suspension travel, makes the Adventure R the ultimate off-road companion.
With its lightweight engineering, extremely powerful engine, and impressive power-to-weight ratio, the 1190 Adventure R is a true masterclass in ride dynamics. And with its standard features like TPMS, steel crash bars, and centre stand, this motorcycle is ready for anything the trail throws its way.
Key Specifications
Engine Type
Four stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Engine Capacity
72.9 cubic inches / 1195 cc
Max Power
147.5 hp / 107.7 kW @ 9500 rpm
Max Torque
92.2 lb-ft / 124.8 Nm @ 7500 rpm
Fuel Tank Capacity
23 Litres / 6.08 gal
Seat Height
35 inches / 890 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM 1190 Adventure R
Year
2014
Engine
Engine Type
Four stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Displacement
72.9 cubic inches / 1195 cc
Bore x Stroke
105 x 69 mm
Compression Ratio
12.5:1
Max Horsepower
147.5 hp / 107.7 kW @ 9500 rpm
Max Torque
92.2 lb-ft / 124.8 Nm @ 7500 rpm
Engine Management System
EFI, ride by wire
Lubrication System
Forced oil lubrication with 3 rotor pumps
Cooling System
Liquid cooling
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet multi-disc clutch, hydraulically operated
Gearbox
6 Speed
Final Drive
Chain 5/8 x 5/16″ X Ring
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Frame Type
Tubular space frame made from chrome molybdenum steel, powder-coated
Front Suspension
48mm WP USD forks
Front Suspension Travel
8.6 inches / 220 mm
Rear Suspension
WP-PDS rear shock, hydraulic spring preload.
Rear Suspension Travel
8.6 inches / 220 mm
Rake
26.0
Trail
129.5 mm / 5.1 in.
Wheels & Brakes
Front Tire Size
90 / 90 ZR21
Rear Tire Size
150/60 ZR18
Front Brakes
2x 320mm discs 4 piston calipers
Rear Brakes
Single 267mm disc 2 piston caliper
Dimension & Weights
Seat Height
35 inches / 890 mm
Wheelbase
62.2 inches / 1580 mm
Ground Clearance
250 mm / 9.8 in(unloaded)
Fuel Tank Capacity
23 Litres / 6.08 gal
Dry Weight
217 kg / 478.4 lb
Features
Four stroke
75V-twin cylinder, DOHC, 4 valves per cylinder
Bosch’s new MSC: Motorcycle Stability Control
Lean-sensitive traction control
ABS with combined braking function
Lean-sensitive cornering ABS
Single-piece/full-length seat for offroad use
Wider aluminium handlebar with “ball-burnished” finish
Longer suspension travel
21″ and 18″ wheel diameters
Standard tyres (90/90 ZR (260) 21 and 150/70 ZR (260) 18)
Smaller windshield
Steel crash bars
Centre stand
TPMS (Tyre Pressure Monitoring System)
Lightweight chrome-molybdenum steel tubular space frame
Highest welding standards
Precisely manufactured tubes
High quality surface finish
Upside-down telescopic fork with 48 mm internal tube diameter
Shock absorber from WP Suspension
