The KTM 1190 Adventure R embodies the unbridled spirit of adventure, with its 75V-twin cylinder engine delivering a raw and sporty riding experience.
The 1190 Adventure R boasts an impressive package, featuring Bosch’s innovative MSC (Motorcycle Stability Control) system as standard. This cutting-edge technology includes lean-sensitive traction control and cornering ABS, elevating the motorcycle to the safest in the world.
With its optimized chassis, increased reserves, and unparalleled off-road ability, the 1190 Adventure R is the ultimate machine for those who live for adventure. Its lightweight construction, paired with an extremely powerful engine, sets it apart in terms of power-to-weight ratio and ride dynamics.
Key Specifications
Engine Type
Four stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Engine Capacity
72.9 cubic inches / 1195 cc
Max Power
147.5 hp / 107.7 kW @ 9500 rpm
Max Torque
92.2 lb-ft / 124.8 Nm @ 7500 rpm
Fuel Tank Capacity
23 Litres / 6.08 gal
Seat Height
35 inches / 890 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM 1190 Adventure R
Year
2013
Engine
Engine Type
Four stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Displacement
72.9 cubic inches / 1195 cc
Bore x Stroke
105 x 69 mm
Compression Ratio
12.5:1
Max Horsepower
147.5 hp / 107.7 kW @ 9500 rpm
Max Torque
92.2 lb-ft / 124.8 Nm @ 7500 rpm
Engine Management System
EFI, ride by wire
Lubrication System
Forced oil lubrication with 3 rotor pumps
Cooling System
Liquid cooling
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet multi-disc clutch, hydraulically operated
Gearbox
6 Speed
Final Drive
Chain 5/8 x 5/16″ X Ring
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Frame Type
Tubular space frame made from chrome molybdenum steel, powder-coated
Front Suspension
48mm WP USD forks
Front Suspension Travel
8.6 inches / 220 mm
Rear Suspension
WP-PDS rear shock, hydraulic spring preload.
Rear Suspension Travel
8.6 inches / 220 mm
Rake
26.0
Trail
129.5 mm / 5.1 in.
Wheels & Brakes
Front Tire Size
90 / 90 ZR21
Rear Tire Size
150/60 ZR18
Front Brakes
2x 320mm discs 4 piston calipers
Rear Brakes
Single 267mm disc 2 piston caliper
Dimension & Weights
Seat Height
35 inches / 890 mm
Wheelbase
62.2 inches / 1580 mm
Ground Clearance
250 mm / 9.8 in(unloaded)
Fuel Tank Capacity
23 Litres / 6.08 gal
Dry Weight
217 kg / 478.4 lb
Features
Four stroke, 75V-twin cylinder engine
DOHC, 4 valves per cylinder
Bosch’s new MSC (Motorcycle Stability Control) as standard
Lean-sensitive traction control
Cornering ABS with lean-sensitive function
Combined braking function
Wider aluminium handlebar with “ball-burnished” finish
Single-piece/full-length seat for offroad use
Longer suspension travel for improved offroad ability
21″ and 18″ wheel diameters for improved offroad ability
Standard tyres (90/90 ZR (260) 21 and 150/70 ZR (260) 18)
Smaller windshield
Steel crash bars as standard
Centre stand as standard
TPMS (Tyre Pressure Monitoring System) as standard
Lightweight chrome-molybdenum steel tubular space frame
Consistent lightweight construction
Excellent chassis geometry
Extremely stable frame
Weighs only 9.8 kg
