The 2015 KTM 1190 Adventure is a benchmark-setting motorcycle that redefines the travel segment. Its 75V-twin cylinder, DOHC engine delivers a potent 150 hp, yet weighs in at a mere 230 kg fully tanked, making it the most agile and responsive bike in its class.
The engine’s power delivery is nothing short of remarkable, offering a seamless transition from relaxed cruising to super-sporty acceleration, with every conceivable level in between. Paired with the chassis’s exceptional geometry and suspension, the result is an unparalleled riding experience that’s as comfortable on long highway stretches as it is on technical off-road terrain.
The addition of Bosch’s MSC (Motorcycle Stability Control) system takes the 1190 Adventure to new heights, combining lean-sensitive traction control, ABS, and a world-first lean-sensitive cornering ABS for unparalleled safety and control. With its impressive fuel efficiency, large 23-litre tank capacity, and long service intervals, the KTM 1190 Adventure is the ultimate travel companion for any rider.
Key Specifications
Engine Type
Four stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Engine Capacity
72.9 cubic inches / 1195 cc
Max Power
147.5 hp / 107.7 kW @ 9500 rpm
Max Torque
92.2 lb-ft /124.8 Nm@ 7500 rpm
Fuel Tank Capacity
6.08 US gallons / 23.0 L
Seat Height
33.9 inches / 861 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
KTM 1190 Adventure
Year
2015
Engine
Engine Type
Four stroke, 75V-twin cylinder, DOHC, 4 valves per cylinder
Displacement
72.9 cubic inches / 1195 cc
Bore x Stroke
105 x 69 mm
Compression Ratio
12.5:1
Max Horsepower
147.5 hp / 107.7 kW @ 9500 rpm
Max Torque
92.2 lb-ft /124.8 Nm@ 7500 rpm
Engine Management System
EFI, ride by wire
Lubrication System
Forced oil lubrication with 3 rotor pumps
Cooling System
Liquid cooling
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet multi-disc clutch, hydraulically operated
Gearbox
6 Speed
Final Drive
Chain 5/8 x 5/16″ X Ring
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Frame Type
Tubular space frame made from chrome molybdenum steel, powder-coated
Front Suspension
48mm WP USD forks
Front Suspension Travel
7.5 inches / 190 mm
Rear Suspension
WP-PDS rear shock, hydraulic spring preload.
Rear Suspension Travel
8.2 inches / 210 mm
Rake
26.0
Trail
119.8 mm / 4.72 in.
Wheels & Brakes
Front Wheel/Rim Size
Spoked aluminum, 3.50 x 19 in.
Front Tire Size
120/70ZR-19
Rear Wheel/Rim Size
Spoked aluminum, 5.00 x 17 in.
Rear Tire Size
170/60ZR-17
Front Brakes
2x 320mm discs 4 piston calipers
Rear Brakes
Single 267mm disc 2 piston caliper
Dimension & Weights
Seat Height
33.9 inches / 861 mm
Wheelbase
63.0 inches / 1600 mm
Ground Clearance
220 mm / 8.7 in
Fuel Tank Capacity
6.08 US gallons / 23.0 L
Dry Weight
217 kg / 478.4 lbs
Features
75V-twin cylinder engine
DOHC with 4 valves per cylinder
150 horsepower
230 kg fully tanked
Power-to-weight ratio previously unheard of in this class
Lean-sensitive traction control
ABS with combined braking function
Lean-sensitive cornering ABS
World’s safest motorcycle
Bosch’s new MSC (Motorcycle Stability Control)
23-litre fuel tank capacity
Low fuel consumption
Long service intervals of 15,000 km
Aluminium handlebar
Ergonomics suitable for all riding situations
Adjustable handlebar clamping position
Completely new tyres for the travel enduro class
Liquid-cooled design
Spark-ignition engine
