Key Specifications Engine Type Air-cooled Thunderstroke 116 Engine Capacity 1890 cc / 116 cu inches Max Power n/a Max Torque 126 ft-lbs / 170.8 Nm @ 2900 rpm Top Speed n/a Fuel Tank Capacity 20.8 L / 5.5 US gallons Weight (Wet/Kerb) 358 kg / 790 lbs Seat Height 650 mm / 25.6 inches
*n/a – information not provided by manufacturer
All Specifications Make & Model Model Indian Springfield Dark Horse Year 2024
Engine Engine Type Air-cooled Thunderstroke 116 Displacement 1890 cc / 116 cu inches Bore x Stroke 103.2 mm x 113 mm Compression Ratio 11 : 1 Number of Cylinders 2 Max Torque 126 ft-lbs / 170.8 Nm @ 2900 rpm Valve Train 2 Valves Per Cylinder, Hydraulic Lifters Valves per Cylinder 2 Engine Management System Closed loop fuel Injection / 54 mm dual bore Lubrication System Semi-Dry Sump Cooling System Air/Oil Cooler Ignition System Fully electronic ignition Fuel 91 pump octane minimum (R+M/2 Method) or 95 RON minimum, E5, E10 Exhaust System Split Dual Exhaust w/ Cross-over
Performance *n/a – information not provided by manufacturer
Transmission Clutch Wet, Multi-Plate, Assist Gearbox 6 Speed / Constant Mesh Primary Drive Ratio 1:564:1 Gear Ratios 1st gear – 2.733:1 Final Drive Belt Drive, 152 Tooth Assist & Slipper Clutch Yes
Electrical & Electronics System Battery 12 Volt, 18 amp/hour, 310 CCA, Sealed Glass Mat Alternator/Generator 710W @ 3500 RPM Headlight Type Non-Serviceable Reflective LED Taillight Type Non-Serviceable Reflective LED Instrumentation 4″ Analog Gauge with Speedometer, Indicator Lamps, and Multi-Function Display Riding Modes 3 Ride Modes – Standard, Tour, Sport Traction Control System Yes ABS Yes Cruise Control Yes
Chassis & Suspension Front Suspension 46 mm Telescopic Fork Front Suspension Travel 119 mm / 4.7 inches Rear Suspension Single Shock w/ Air adjust Rear Suspension Travel 114 mm / 4.5 inches Rake 25 ° Trail 133 mm / 5.2 inches Swingarm Steel Handlebar Mid Rise Handlebar
Wheels & Brakes Wheels 10-Spoke Contrast Cut Front Wheel/Rim Size 3.5 x 19″ Front Tire Size 130/60B19 66H Metzeler Cruisetec Rear Wheel/Rim Size 5 x 16″ Rear Tire Size 180/60R16 80H Metzeler® Cruisetec Front Brakes Dual / 300mm floating rotor / with 4-piston calipers Rear Brakes Single / 300 mm Floating Rotor / 2 Piston Caliper
Dimension & Weights Overall Length 2522 mm / 99.3 inches Overall Width 972 mm / 38.3 inches Overall Height 1226 mm / 48.3 inches Seat Height 650 mm / 25.6 inches Wheelbase 1701 mm / 67 inches Ground Clearance 130 mm / 5.1 inches Fuel Tank Capacity 20.8 L / 5.5 US gallons Wet (kerb/curb) Weight 358 kg / 790 lbs Dry Weight 344 kg / 758 lbs
Standard Equipment Remote-Locking Hard Saddlebags Vinyl Rogue Seat Tire Pressure Monitoring Light Bar ABS Selectable Ride Modes Cruise Control Keyless Ignition Indian Springfield Dark Horse (2024) Color Options Black Smoke SageBrush Smoke *We strive to provide the most comprehensive and accurate specifications possible. However, certain details may not be available if the manufacturer did not disclose them or if the information is no longer publicly accessible. If you find any discrepancy with any data on this site, please feel free to let us know at contact@throttlecraze.com
