Key Specifications Engine Type Air-cooled Thunderstroke 111 Engine Capacity 1811 cc / 111 cu inches Max Power n/a Max Torque 119 ft-lbs / 161.34 Nm @ 3000 rpm Top Speed n/a Fuel Tank Capacity 20.8 L / 5.5 US gallons Weight (Wet/Kerb) 376 kg / 827 lbs Seat Height 660 mm / 26 inches
*n/a – information not provided by manufacturer
All Specifications Make & Model Model Indian Springfield Year 2024
Engine Engine Type Air-cooled Thunderstroke 111 Displacement 1811 cc / 111 cu inches Bore x Stroke 101 mm x 113 mm Compression Ratio 9.5 : 1 Number of Cylinders 2 Max Torque 119 ft-lbs / 161.34 Nm @ 3000 rpm Valve Train 2 Valves Per Cylinder, Hydraulic Lifters Valves per Cylinder 2 Engine Management System Closed loop fuel Injection / 54 mm dual bore Lubrication System Semi-Dry Sump Cooling System Air/Oil Cooler Ignition System Fully electronic ignition Fuel 91 pump octane minimum (R+M/2 Method) or 95 RON minimum, E5, E10 Exhaust System Split Dual Exhaust w/ Cross-over
Performance *n/a – information not provided by manufacturer
Transmission Clutch Wet, Multi-Plate, Assist Gearbox 6 Speed / Constant Mesh Primary Drive Ratio 1:564:1 Gear Ratios 1st gear – 2.733:1 Final Drive Belt Drive, 152 Tooth Assist & Slipper Clutch Yes
Electrical & Electronics System Battery 12 Volt, 18 amp/hour, 310 CCA, Sealed Glass Mat Alternator/Generator 710W @ 3500 RPM Headlight Type Non-Serviceable Reflective LED Taillight Type Non-Serviceable Reflective LED Instrumentation 4″ Analog Gauge with Speedometer, Indicator Lamps, and Multi-Function Display Riding Modes 3 Ride Modes – Standard, Tour, Sport Traction Control System Yes ABS Yes Cruise Control Yes
Chassis & Suspension Front Suspension 46 mm Telescopic Fork Front Suspension Travel 119 mm / 4.7 inches Rear Suspension Single Shock w/ Air adjust Rear Suspension Travel 114 mm / 4.5 inches Rake 25 ° Trail 133 mm / 5.2 inches Swingarm Steel
Wheels & Brakes Wheels Highlight Machine Tour Front Wheel/Rim Size 3.5 x 17″ Front Tire Size 130/80B17 65H Metzeler Cruisetec Rear Wheel/Rim Size 5 x 16″ Rear Tire Size 180/60R16 80H Metzeler® Cruisetec Front Brakes Dual / 300mm floating rotor / with 4-piston calipers Rear Brakes Single / 300 mm Floating Rotor / 2 Piston Caliper
Dimension & Weights Overall Length 2583 mm / 101.7 inches Overall Width 1080 mm / 42.5 inches Overall Height 1439 mm / 56.6 inches Seat Height 660 mm / 26 inches Wheelbase 1701 mm / 67 inches Ground Clearance 142 mm / 5.6 inches Fuel Tank Capacity 20.8 L / 5.5 US gallons Wet (kerb/curb) Weight 376 kg / 827 lbs Dry Weight 362 kg / 795 lbs
Standard Equipment Quick Release Windshield Genuine Leather Seat Remote-Locking Hard Saddlebags Highway Bars Tire Pressure Monitoring Light Bar Selectable Ride Modes ABS Cruise Control Keyless Ignition Indian® Script Tank Badge 12v Charging Port Indian Springfield (2024) Color Options Black Metallic / Titanium Metallic Bronze Pearl / Silver Quartz *We strive to provide the most comprehensive and accurate specifications possible. However, certain details may not be available if the manufacturer did not disclose them or if the information is no longer publicly accessible. If you find any discrepancy with any data on this site, please feel free to let us know at contact@throttlecraze.com
