Indian Springfield (2018 – 2019)

Indian Springfield (2018 - 2019)

The Indian Springfield is a masterclass in classic design and rider-centric innovation. This stylish machine boasts a stunning, pure and classic aesthetic, while its impressive feature list includes Ride Modes, Rear Cylinder Deactivation, and a host of rider-favorite amenities like a quick-release windshield and genuine leather seats.

At its heart lies the Thunder Stroke 111 V-Twin, a soul-stirring engine that delivers smooth, impressive power in every gear. This powerhouse is elevated by the introduction of Ride Modes, which allow riders to tailor their experience to their preferred style – be it relaxed touring, spirited standard riding, or head-snapping sport mode.

Whether cruising through the countryside or carving up twisties, the Indian Springfield is engineered to provide an unparalleled riding experience, with Rear Cylinder Deactivation adding an extra layer of comfort. With its impressive array of features and the potent Thunder Stroke 111 under the tank, this motorcycle is truly the ultimate machine for those who crave the freedom of the open road.

Key Specifications

Engine TypeThunder Stroke 111 49˚ V-Twin
Engine Capacity111 cubic inches / 1811. cc
Fuel Tank Capacity5.5 US gallons / 20.8 L
Seat Height26.0 inches / 660 mm
Indian Springfield (2018 - 2019)

All Specifications

Make & Model

ModelIndian Springfield
Year2018 – 2019

Engine

Engine TypeThunder Stroke 111 49˚ V-Twin
Displacement111 cubic inches / 1811. cc
Bore x Stroke101 x 113 mm
Compression Ratio9.5:1
Engine Management SystemElectronic Fuel Injection System Closed loop fuel injection / 54mm bore
ExhaustSplit dual exhaust with crossover

Performance

Top Speedn/a

Transmission

ClutchWet, Multi-Plate
Gearbox6 Speed
Gear Ratios1st 9.403 : 1 2nd 6.411 : 1 3rd 4.763 : 1 4th 3.796 : 1 5th 3.243 : 1 6th 2.789 : 1
Final DriveBelt drive, 152 tooth

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeCast Aluminum Frame with Integrated Air-Box
Front Suspension46mm Telescopic forks
Front Suspension Travel4.7 inches / 119 mm
Rear SuspensionSingle Shock w/ Air Adjust
Rear Suspension Travel4.5 inches / 114 mm
Rake25
Trail133mm / 5.2 in

Wheels & Brakes

Front Tire SizeDunlop American Elite 130/60B19 61H
Rear Tire SizeDunlop Elite 3 180/60R16 80H
Front Brakes2x 300 mm Floating Rotor 4 piston calipers
Rear BrakesSingle 300 mm Floating Rotor 2 piston calipers

Dimension & Weights

Seat Height26.0 inches / 660 mm
Wheelbase67.0 inches / 1700 mm
Ground Clearance142 mm / 5.6 in
Fuel Tank Capacity5.5 US gallons / 20.8 L
Dry Weight349 kg / 770 lbs

Features

  • Quick release windshield
  • Genuine leather seats
  • Remote-locking saddlebags
  • Adjustable passenger floorboards
  • ABS
  • Cruise control
  • Keyless ignition
  • Tire pressure monitoring
  • Thunder Stroke 111 V-Twin engine
  • Selectable Ride Modes (Tour, Standard, Sport)
  • Rear Cylinder Deactivation
  • Improved audio system (Roadmaster)
  • Gloss black finishes (Dark Horse models)
  • Lower fairings with adjustable airflow vent (Roadmaster)
  • Redesigned lower fairings for improved airflow
  • Rear cylinder deactivation for improved comfort
  • Seamless transition to full power with rear cylinder reactivation
