Indian Springfield (2016 – 2017)

Indian Springfield (2016 - 2017)

The Indian Springfield is a masterful blend of heritage and innovation, born from the rich history of Indian Motorcycle. This soulful and versatile bike is designed to deliver a pure riding experience, with authentic American craftsmanship and refined touring features that won’t distract from the joy of the open road.

At its heart, the Indian Springfield boasts a robust engine character that’s both powerful and refined, making it perfect for carving through twisties or cruising down the highway. Its modern technology and classic styling come together in perfect harmony, creating a truly unique riding experience.

Whether you’re hitting the highway or navigating the urban jungle, the Indian Springfield is a capable and comfortable companion, with standard features like real leather seating, high-resolution Anti-Lock Brakes, and electronic cruise control. And with its quick-release windshield and removable saddlebags, you can easily adapt the bike to suit your riding style.

But what truly sets the Indian Springfield apart is its ability to balance style, luxury, and functionality, making it an unforgettable ride that’s sure to leave a lasting impression. Whether you’re a seasoned touring veteran or just starting to explore the world of long-distance riding, the Indian Springfield is an exceptional choice that’s sure to exceed your expectations.

Key Specifications

Engine TypeThunder Stroke 111
Engine Capacity111 cubic inches / 1811. cc
Fuel Tank Capacity5.5 US gallons / 20.8 L
Weight (Wet/Kerb)852 lbs / 388 kg
Seat Height26.0 inches / 660 mm
Indian Springfield (2016 - 2017)

All Specifications

Make & Model

ModelIndian Springfield
Year2016 – 2017

Engine

Engine TypeThunder Stroke 111
Displacement111 cubic inches / 1811. cc
Bore x Stroke101 x 113 mm
Compression Ratio9.5:1
Engine Management SystemElectronic Fuel Injection System Closed loop fuel injection / 54mm bore
ExhaustSplit Dual Exhaust w/ Cross-Over

Performance

Top Speedn/a

Transmission

ClutchWet, Multi-Plate
Gearbox6 Speed
Gear Ratios1st 9.403 : 1 2nd 6.411 : 1 3rd 4.763 : 1 4th 3.796 : 1 5th 3.243 : 1 6th 2.789 : 1
Final DriveBelt

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeCast Aluminum Frame with Integrated Air-Box
Front Suspension46mm Telescopic forks
Front Suspension Travel4.7 inches / 119 mm
Rear SuspensionSingle Shock w/ Air Adjust
Rear Suspension Travel4.5 inches / 114 mm
Rake25
Trail133mm / 5.2 in

Wheels & Brakes

Front Tire SizeDunlop Elite 3 130 / 90B16 73H
Rear Tire SizeDunlop Elite 3 Multi-Compound 180/60R16 80H
Front Brakes2×300 mmFloating Rotor 4 piston calipers
Rear BrakesSingle300 mmFloating Rotor 2 piston calipers

Dimension & Weights

Seat Height26.0 inches / 660 mm
Wheelbase67.0 inches / 17010 mm
Ground Clearance142 mm / 5.6 in
Fuel Tank Capacity5.5 US gallons / 20.8 L
Wet (kerb/curb) Weight852 lbs / 388 kg
Dry Weight372 kg / 818 lbs

Features

  • Bespoke quick-release windshield
  • Remote locking hard bags
  • Adjustable passenger floorboards
  • Real leather seating
  • High-resolution Anti-Lock Brakes
  • Tire pressure monitoring
  • Electronic cruise control
  • Powerful headlight and dual driving lights
  • Standard front and rear highway bars
  • Brightly chromed forks
  • Headlight housing
  • Fender trim
  • Engine covers
  • Exhaust
  • Handlebars with internal wiring
  • Thunder Stroke 111 engine
  • 119 ft./lbs. of torque
  • Cartridge forks
  • Air adjustable rear shock
  • 4.5 inches of travel
