Indian FTR1200 (2021)

Indian FTR1200 (2021)

Indian Motorcycle is pushing the boundaries of American V-Twin performance with the 2022 FTR lineup, a testament to the brand’s commitment to innovation and excellence.

The FTR’s engine character has been refined to deliver a smoother, more predictable throttle response, while its cylinder deactivation system ensures efficient engine heat management.

With a perfect balance of style and performance, the FTR offers an unmatched riding experience, featuring a 110mm digital touchscreen display, a 1203cc liquid-cooled V-twin engine producing 123 hp and 88.5 ft-lb of torque.

The 2022 FTR lineup is the culmination of meticulous attention to detail, with the flagship FTR R Carbon boasting top-quality Hlins units and a range of upgrades that elevate its street performance credentials.

Key Specifications

Engine TypeFour stroke, 60 V Twin , DOHC, 4 valves per cylinder, graded buckets
Engine Capacity73 cubic inches / 1203 cc
Max Power120 hp / 89.4 kW @ 6000 rpm
Max Torque87 ft-lb / 117.9 nm
Fuel Tank Capacity3.4 US gallons / 12.9 L
Seat Height33.1 inches / 840 mm
Indian FTR1200 (2021)

All Specifications

Make & Model

ModelIndian FTR1200
Year2021

Engine

Engine TypeFour stroke, 60 V Twin , DOHC, 4 valves per cylinder, graded buckets
Displacement73 cubic inches / 1203 cc
Bore x Stroke102 x 73.6 mm
Compression Ratio12.5:1
Max Horsepower120 hp / 89.4 kW @ 6000 rpm
Max Torque87 ft-lb / 117.9 nm
Engine Management SystemElectronic Fuel Injection closed loop, 60 mm bore
Cooling SystemLiquid Cooled
Exhaust2-into-1

Performance

Top Speedn/a

Transmission

ClutchAssist & Slip, Multi-Plate
Gearbox6 Speed
Gear Ratios1st 12.270:1 2nd 8.341:1 3rd 6.646:1 4th 5.639:1 5th 4.985:1 6th 4.278:1
Final DriveChain

Electrical & Electronics System

StarterElectric
ABSStandard, option to disable

Chassis & Suspension

Frame TypeSteel trellis
Front Suspension43 mm ZF Sachs fully adjustable inverted telescopic cartidge fork
Front Suspension Travel4.7 inches / 120 mm
Rear SuspensionZF Sachs fully adjustable piggyback IFP
Rear Suspension Travel4.7 inches / 120 mm
Rake25.3
Trail99.9 mm / 3.9 in

Wheels & Brakes

Front Wheel/Rim SizeCast Black with Indy Red Pinstripe 17 in x 3.5 in
Front Tire Size120/70ZR17 58W Metzeler Sportec
Rear Wheel/Rim SizeCast Black with Indy Red Pinstripe 17 in x 5.5 in
Rear Tire Size180/55ZR17 73W Metzeler Sportec
Front Brakes2x 320mm t5 Rotor Brembo with 4-piston calipers
Rear BrakesSingle 260mm t5 RotorBrembowith 2-piston calipers
ABSStandard, option to disable

Dimension & Weights

Seat Height33.1 inches / 840 mm
Wheelbase60 inches / 1524 mm
Ground Clearance170 mm / 6.5 in
Fuel Tank Capacity3.4 US gallons / 12.9 L

Features

  • 1203cc liquid-cooled V-twin engine
  • 92 kW (123 hp) of power
  • 120 Nm (88.5 ft-lb) of torque
  • 110mm (4.3-inch) digital touchscreen display
  • Fully-adjustable suspension
  • Metzeler Sportec street tyres
  • 17-inch cast aluminium wheels
  • Inverted front suspension
  • Radially mounted dual Brembo brakes
  • Cruise control
  • Cylinder deactivation
  • Engine calibration for smoother throttle response
  • Lower seat height
  • Shorter trail of 99.9 mm
  • Steeper rake angle of 25
  • ProTaper handlebars trimmed by 40mm (1.5-inches)
  • Analogue gauge (on base FTR)
  • i (on base FTR)
  • Hlins units (on FTR R Carbon)
