Indian FTR 1200R Carbon (2021)

Indian FTR 1200R Carbon (2021)

Indian Motorcycle has elevated the FTR platform to unprecedented heights with the 2021 FTR 1200R Carbon. This exceptional machine boasts a unique blend of style and performance, courtesy of its 1203cc liquid-cooled V-twin engine, producing 92 kW (123 hp) and 120 Nm (88.5 ft-lb) of torque.

The 2021 FTR 1200R Carbon is a masterclass in refinement, with engine performance optimized for a smoother, more predictable throttle response. Cylinder deactivation ensures efficient engine heat management when idling. The bike’s handling is further enhanced by a steeper rake angle, shorter trail, and precise 17-inch cast aluminium wheels wrapped with Metzeler Sportec street tyres.

With its perfectly balanced blend of style and performance, the FTR 1200R Carbon delivers a truly exceptional riding experience, redefining the boundaries of what an American V-Twin can be.

Key Specifications

Engine TypeFour stroke, 60 V Twin , DOHC, 4 valves per cylinder, graded buckets
Engine Capacity73 cubic inches / 1203 cc
Max Power120 hp / 89.4 kW @ 6000 rpm
Max Torque87 ft-lb / 117.9 nm
Fuel Tank Capacity3.4 US gallons / 12.9 L
Seat Height30.7 inches / 780 mm
Indian FTR 1200R Carbon (2021)

All Specifications

Make & Model

ModelIndian FTR 1200R Carbon
Year2021

Engine

Engine TypeFour stroke, 60 V Twin , DOHC, 4 valves per cylinder, graded buckets
Displacement73 cubic inches / 1203 cc
Bore x Stroke102 x 73.6 mm
Compression Ratio12.5:1
Max Horsepower120 hp / 89.4 kW @ 6000 rpm
Max Torque87 ft-lb / 117.9 nm
Engine Management SystemElectronic Fuel Injection closed loop, 60 mm bore
Cooling SystemLiquid Cooled
ExhaustAkrapovič2-into-1

Performance

Top Speedn/a

Transmission

ClutchAssist & Slip, Multi-Plate
Gearbox6 Speed
Gear Ratios1st 12.270:1 2nd 8.341:1 3rd 6.646:1 4th 5.639:1 5th 4.985:1 6th 4.278:1
Final DriveChain

Electrical & Electronics System

StarterElectric
ABSStandard, option to disable

Chassis & Suspension

Frame TypeSteel trellis
Front Suspension43 mm hlins fully adjustable inverted telescopic cartidge fork
Front Suspension Travel4.7 inches / 120 mm
Rear Suspensionhlins fully adjustable piggyback IFP
Rear Suspension Travel4.7 inches / 120 mm
Rake25.3
Trail99.9 mm / 3.9 in

Wheels & Brakes

Front Wheel/Rim SizeCast Black with Indy Red Pinstripe 17 in x 3.5 in
Front Tire Size120/70ZR17 58W Metzeler Sportec
Rear Wheel/Rim SizeCast Black with Indy Red Pinstripe 17 in x 5.5 in
Rear Tire Size180/55ZR17 73W Metzeler Sportec
Front Brakes2x 320mm t5 Rotor Brembo with 4-piston calipers
Rear BrakesSingle 260mm t5 RotorBrembowith 2-piston calipers
ABSStandard, option to disable

Dimension & Weights

Seat Height30.7 inches / 780 mm
Wheelbase60 inches / 1524 mm
Ground Clearance170 mm / 6.5 in
Fuel Tank Capacity3.4 US gallons / 12.9 L

Features

  • 110mm (4.3-inch) digital touchscreen display
  • 1203cc liquid-cooled V-twin engine
  • 92 kW (123 hp) of power
  • 120 Nm (88.5 ft-lb) of torque
  • Radially mounted dual Brembo brakes
  • Cruise control
  • Fully-adjustable front and rear suspension
  • Cylinder deactivation for engine heat management
  • New engine calibration for smoother throttle response
  • Metzeler Sportec tyres
  • 17-inch cast aluminium wheels
  • Hlins front and rear suspension on FTR R Carbon
  • Lower seat height by 36mm (1.4-inches)
  • ProTaper handlebars trimmed by 40mm (1.5-inches)
  • Steeper head angle
  • Shorter trail
  • Asphalt-oriented 17 tyres and wheels
