Indian Chieftain Dark Horse (2016 – 2017)

Indian Chieftain Dark Horse (2016 - 2017)

The Indian Chieftain Dark Horse is a bagger with undeniable presence, its matte black finish and aggressive attitude commanding attention on the road. Powered by the Thunder Stroke 111 engine, this American-made V-twin touring bike delivers a raw, unbridled performance that’s unmatched in its class.

Its edgy design is not just skin-deep, as the Dark Horse boasts a wealth of features that set it apart from the competition, including ABS, electronic cruise control, and a premium audio system. The bike’s chassis and suspension are identical to the highly lauded Chieftain, ensuring a smooth and responsive ride.

But what truly sets the Dark Horse apart is its customizability, with a vast array of authentic factory accessories available to further individualize its already stealthy ride. With a Blackout series accessory air cleaners, performance cams, and slip-on exhausts, riders can take their Dark Horse to new heights of style and performance.

With its blacked-out styling and powerful Thunder Stroke 111 engine, the Indian Chieftain Dark Horse is the ultimate ride for those who crave raw power and unbridled freedom, and are ready to take their riding experience to the top of the pack.

Key Specifications

Engine TypeFour stroke, V-twin, Thunder Stroke 111
Engine Capacity1818 cc / 111 cu in
Fuel Tank Capacity20.8 Litres / 5.5 gal
Weight (Wet/Kerb)848 lbs / 385 kg
Seat Height26.0 inches / 660 mm
Indian Chieftain Dark Horse (2016 - 2017)

All Specifications

Make & Model

ModelIndian Chieftain Dark Horse
Year2016 – 2017

Engine

Engine TypeFour stroke, V-twin, Thunder Stroke 111
Displacement1818 cc / 111 cu in
Bore x Stroke101x 113 mm
Compression Ratio9.5:1
Engine Management SystemElectronic Fuel Injection System Closed loop fuel injection / 54mm bore
Cooling SystemAir cooled
ExhaustSystem Split dual exhaust w/ cross-over

Performance

Top Speedn/a

Transmission

ClutchWet, Multi-Plate
Gearbox6 Speed
Gear Ratios1st 9.403 : 1 2nd 6.411 : 1 3rd 4.763 : 1 4th 3.796 : 1 5th 3.243 : 1 6th 2.789 : 1
Final Drive2.2 : 1

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeHigh tensile steel, monoshock
Front SuspensionTelescopic forks
Front Suspension Travel4.7 inches / 120 mm
Rear SuspensionSingle shock
Rear Suspension Travel95 mm 3.7 in
Rake29
Trail155 mm / 6.1 in

Wheels & Brakes

Wheels60 Spoke 16″ x 3.5″ Front and 16″ x 5″ Rear
Front Tire Size130/90B16 67H
Rear Tire Size180/65B16 81H
Front Brakes2x Floating Rotor 4 piston calipers
Rear BrakesSingle Floating Rotor 2 piston calipers

Dimension & Weights

Seat Height26.0 inches / 660 mm
Wheelbase65.7 inches / 1668 mm
Ground Clearance140 mm / 5.5 in
Fuel Tank Capacity20.8 Litres / 5.5 gal
Wet (kerb/curb) Weight848 lbs / 385 kg
Dry Weight370 kg / 815 lbs

Features

  • Solo seat
  • Short, tinted power windscreen
  • Hard bags
  • ABS
  • Electronic cruise control
  • Integrated premium audio system
  • Remote key fob with keyless ignition
  • Matte black paint
  • Thunder Stroke 111 engine
  • Blacked-out fenders, fairing, fuel tank, and bags
  • Blacked-out iconic Indian Motorcycle headdress
  • Blacked-out forks, mirrors, handlebars, and switch cubes
  • Blacked-out turn signals, tank console, engine, and airbox cover
  • Blacked-out lower controls, floorboards, and taillight housing
  • Blackout series accessory air cleaners
  • Performance cams
  • Slip-on exhausts
  • 100-watt saddlebag lid speakers
