The Husqvarna Vitpilen 401 is a motorcycle that embodies the perfect blend of modern thinking and classic design. Powered by a strong, 44 hp single-cylinder EURO 5-compliant engine, this bike is equally at home in urban environments or out-of-town.
The dynamic chassis, inviting dimensions, and low weight result in an engaging ride, while WP suspension provides exemplary handling with perfect rider feedback. ByBre brakes and Bosch ABS ensure exceptional stopping power, making this bike a true joy to ride.
With its trellis frame, made from high-strength steel, the Vitpilen 401 exudes agility and nimbleness, providing detailed feedback to the rider. The state-of-the-art Easy Shift function and ride-by-wire throttle further enhance the riding experience, making this bike a true standout in its class. The Vitpilen 401 is a motorcycle that truly embodies the spirit of adventure and freedom.
Key Specifications
Engine Type
Four stroke, single cylinder, DOHC with cam levers, 4 valves
Engine Capacity
22.8 cubic inches / 373.2 cc
Max Power
44 hp / 32 kW @ 9000 rpm
Max Torque
27.3 ft-lb / 37 nm
Fuel Tank Capacity
2.5 US gallons / 9.5 L
Weight (Wet/Kerb)
332.8 lbs / 151 kg
Seat Height
32.8 inches / 835 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Husqvarna Vitpilen 401
Year
2022
Engine
Engine Type
Four stroke, single cylinder, DOHC with cam levers, 4 valves
Displacement
22.8 cubic inches / 373.2 cc
Bore x Stroke
89 x 60 mm
Compression Ratio
12.6:1
Max Horsepower
44 hp / 32 kW @ 9000 rpm
Max Torque
27.3 ft-lb / 37 nm
Engine Management System
Bosch EFI (throttle body 46 mm)
Lubrication System
Wet sump with 2 oil pumps
Cooling System
Liquid cooled
Exhaust
Stainless steel / Aluminum silencer with regulated catalytic converter
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Multi disc slipper clutch
Gearbox
6 Speed
Primary Drive Ratio
30:80
Final Drive
Chain, X-Ring 5/8 x 1/4″
Electrical & Electronics System
Starter
Electric
ABS
Two channel Bosch 10.1MB
Chassis & Suspension
Frame Type
Steel trellis frame, powder coated
Front Suspension
43mmWP APEX upside-down forks, with compression rebound adjustability
Front Suspension Travel
5.6 inches / 142 mm
Rear Suspension
WP APEX monoshock with preload adjustability
Rear Suspension Travel
5.6 inches / 142 mm
Rake
25
Trail
95 mm / 3.7 in
Wheels & Brakes
Wheels
Spoked wheels with aluminium rims
Front Wheel/Rim Size
3.00 x 17
Front Tire Size
110/70-R17 Metzeler M5
Rear Tire Size
150/60-R17 Metzeler M5
Front Brakes
Single 320mm disc, ByBre 4 piston caliper
Rear Brakes
Single 230mm disc, ByBre, single piston, floating caliper
ABS
Two channel Bosch 10.1MB
Dimension & Weights
Seat Height
32.8 inches / 835 mm
Wheelbase
53.4 inches / 15.5 mm
Ground Clearance
145 mm / 5.6 in
Fuel Tank Capacity
2.5 US gallons / 9.5 L
Wet (kerb/curb) Weight
332.8 lbs / 151 kg
Features
EURO 5-compliant 373 cc single-cylinder engine
44 hp engine output
Dynamic chassis
Inviting dimensions
Low weight
WP suspension
ByBre brakes
Bosch ABS
Easy Shift function
Ride-by-wire throttle
Trellis frame
Hydro-formed tubes and robot welding
High-strength steel frame
Lightweight swingarm
WP monoshock
WP APEX 43 mm open-cartridge forks
Split damping function
Compression and rebound adjustment
Clickers for adjustment on Vitpilen 401 and Svartpilen 401
Progressive spring design on WP APEX monoshock
