The Vitpilen 401 is an unassuming hero of the sub-500 cc world, boasting a unique blend of surefootedness, light weight, and immersive riding position that guarantees helmet-hidden smiles. Its feather-light inputs and instant throttle response make it a joy to guide, with every road texture feeding back through low-slung bars.
The 373cc single-cylinder engine is a masterpiece of modern design, delivering 37Nm of torque from low down in the RPM range and a refined power delivery thanks to electronic fuel injection and ride-by-wire system. With a peak horsepower of 32 kW (44 hp), the Vitpilen 401 is accessible to a wide variety of riders, while its lightweight construction means the power-to-weight ratio will also excite more experienced riders.
At the heart of the Vitpilen 401’s character and agility is its trellis frame, made from high-strength chromium molybdenum steel using hydro-formed tubes and robot welding. The frame’s specific flex characteristics work in harmony with the WP suspension to offer a comfortable and confident feel, combined with a tight turning circle for ease of use in urban environments.
The Vitpilen 401 is also fitted with hydraulic ByBre brake callipers, manufactured to the highest standards, and in combination with 320mm front and 230mm rear perforated steel discs, deliver controllable and confident braking performance. The result is an all-encompassing and sensory ride that resonates with new and experienced riders alike, making the Vitpilen 401 the ultimate urban companion.
Key Specifications
Engine Type
Four stroke, single cylinder, DOHC, 4 valve
Engine Capacity
22.8 cubic inches / 373.2 cc
Max Power
43 hp / 32 kW @ 9000 rpm
Max Torque
27.3 ft-lb / 37 nm
Fuel Tank Capacity
2.5 US gallons / 9.5 L
Weight (Wet/Kerb)
330.6 lbs / 150 kg
Seat Height
32.8 inches / 835 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Husqvarna Vitpilen 401
Year
2020 – 2021
Engine
Engine Type
Four stroke, single cylinder, DOHC, 4 valve
Displacement
22.8 cubic inches / 373.2 cc
Bore x Stroke
89 x 60 mm
Compression Ratio
12.6:1
Max Horsepower
43 hp / 32 kW @ 9000 rpm
Max Torque
27.3 ft-lb / 37 nm
Engine Management System
Fuel injection
Lubrication System
Wet sump
Cooling System
Liquid cooled
Exhaust
Stainless steel/ Aluminum silencer with regulated catalytic converter
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
PASC antihopping clutch, mechanically operated
Gearbox
6 Speed
Final Drive
Chain, X-Ring 5/8 x 1/4″
Electrical & Electronics System
Starter
Electric
ABS
Bosch 9M+ two-channel ABS (disengageable)
Chassis & Suspension
Frame Type
Steel trellis frame, powder coated
Front Suspension
43mm WP upside-down forks
Front Suspension Travel
5.5 inches / 142 mm
Rear Suspension
WP monoshock
Rear Suspension Travel
5.9 inches / 150 mm
Rake
25
Trail
95 mm / 3.7 in
Wheels & Brakes
Front Wheel/Rim Size
Wire-spoked w/ aluminum rims 3.00 x 17
Front Tire Size
110/70 – 17 Pirelli Scorpion Rally STR
Rear Tire Size
150/60 – 17 Pirelli Scorpion Rally STR
Front Brakes
Single 320mm disc, 4 piston floating calliper
Rear Brakes
Single 230mm disc 1 piston floating calliper
ABS
Bosch 9M+ two-channel ABS (disengageable)
Dimension & Weights
Seat Height
32.8 inches / 835 mm
Wheelbase
53.4 inches / 15.5 mm
Ground Clearance
170 mm / 6.7 in
Fuel Tank Capacity
2.5 US gallons / 9.5 L
Wet (kerb/curb) Weight
330.6 lbs / 150 kg
Features
373cc single-cylinder engine
37Nm of torque from low down in the RPM range
6-speed gearbox
Electronic fuel injection with ride-by-wire system
Peak horsepower of 32 kW (44 hp)
Lightweight construction
Power-to-weight ratio for experienced riders
Trellis frame made from high strength chromium molybdenum steel
Hydro formed tubes and robot welding for strength and lightness
WP suspension with 43 mm open cartridge forks
Progressive damping system connected to the swingarm
Hydraulic ByBre brake callipers
320mm front and 230mm rear perforated steel discs
Bosch ABS system
17″ anodised spoked wheels
Reduced weight for improved handling
Classic thinking and modern design blend
Intelligently designed bodywork for seamless movement
