The Husqvarna TR 650 Terra embodies the essence of adventure, its slim, wiry design and masculine lines exuding a sense of progressive agility and energetic riding dynamics.
The Terra’s liquid-cooled single-cylinder engine, based on the G 650 GS by BMW Motorrad, has been extensively modified to deliver a potent 43 kW (58 hp) at 7,250 rpm, with maximum torque of 60 Nm at 5,750 rpm.
Ride the Terra and you’ll experience the thrill of a powerful, high-revving engine that responds spontaneously to your every input, thanks to its advanced electronic fuel-injection system, altered camshafts, and increased compression ratio.
The result is a motorcycle that’s as at home on light terrain as it is on asphalt, offering a unique combination of handling, riding dynamics, and design that sets it apart from its competitors.
Key Specifications
Engine Type
Four stroke, single cylinder, DOHC, 4 valves
Engine Capacity
39.79 cubic inches / 652 cc
Max Power
58 hp /42.1kW @ 7250 rpm
Max Torque
60 Nm / 44 ft-lb @ 5750 rpm
Fuel Tank Capacity
3.5 US gallons / 12.3 L
Weight (Wet/Kerb)
410 lbs / 186 kg
Seat Height
33.8 inches / 853.5 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Husqvarna TR 650 Terra
Year
2013 – 2014
Engine
Engine Type
Four stroke, single cylinder, DOHC, 4 valves
Displacement
39.79 cubic inches / 652 cc
Bore x Stroke
100 x 83 mm
Compression Ratio
12.3:
Max Horsepower
58 hp /42.1kW @ 7250 rpm
Max Torque
60 Nm / 44 ft-lb @ 5750 rpm
Engine Management System
Marelli EFI
Cooling System
Liquid cooled
Exhaust
Closed-loop 3-way catalytic converter
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet, multi-plate
Gearbox
5 Speed
Final Drive
Chain
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Front Suspension
Sachs 46mm, inverted forks
Front Suspension Travel
7.5 inches / 190 mm
Rear Suspension
Sachs, single shock, link-mount
Rear Suspension Travel
7.5 inches / 190 mm
Rake
26
Trail
100 mm / 3.9 in
Wheels & Brakes
Front Tire Size
110/80 -19
Rear Tire Size
140/80 -18
Front Brakes
Brembo hydraulic single 300mm disc
Rear Brakes
Brembo hydraulic single 240mm disc
Dimension & Weights
Seat Height
33.8 inches / 853.5 mm
Wheelbase
59.1 inches / 1501 mm
Fuel Tank Capacity
3.5 US gallons / 12.3 L
Wet (kerb/curb) Weight
410 lbs / 186 kg
Features
652 cc liquid-cooled single-cylinder engine
Two overhead camshafts
43 kW (58 hp) at 7,250 rpm
60 Nm of torque at 5,750 rpm
Reduced power version available (35 kW/48 hp)
Electronic fuel-injection system
Altered camshafts
Increased compression ratio
Stainless steel exhaust system
Closed-loop 3-way catalytic converter
Constant-mesh 5-speed gearbox
Agile chassis based on split-backbone tubular steel frame
Remove-able rear frame
Front beam bolted to engine
46 mm upside-down telescopic fork
Torsionally-stiff dual swing arm made of pentagonal steel tubing
Centrally-mounted rear shock with progressive linkage
