Husqvarna TE 510ie (2008 – 2009)

Husqvarna TE 510ie (2008 - 2009)

The Husqvarna TE 510ie is a testament to the brand’s commitment to innovation and performance. Its steel single tube cradle frame provides a solid foundation for the bike’s impressive capabilities, while the rear frame in light alloy 50mm Marzocchi Upside-Down telescopic hydraulic fork with advanced axle ensures precise handling.

The 2008 model boasts a host of upgrades, including a redesigned riding position, improved ergonomics, and a more powerful engine. The fuel-injected powerplant is a masterclass in engineering, delivering a thrilling ride experience that’s both exhilarating and predictable.

But it’s not just about the numbers – the TE 510ie’s true magic lies in its ability to connect rider and machine, providing an immersive experience that’s as much about the journey as the destination. Whether you’re carving through twisties or tackling the toughest trails, this bike will leave you breathless and begging for more. With its cutting-edge technology and razor-sharp handling, the Husqvarna TE 510ie is an adventure waiting to happen.

Key Specifications

Engine TypeFour stroke, single cylinder, DOHC, 4 valves
Engine Capacity30.5 cubic inches / 501 cc
Max Power59.8 hp / 44 kW @ 8000 rpm
Max Torque56 ft-lb / 49 nm
Fuel Tank Capacity1.9 US gallons / 7.2 L
Seat Height37.9 inches / 963 mm
Husqvarna TE 510ie (2008 - 2009)

All Specifications

Make & Model

ModelHusqvarna TE 510ie
Year2008 – 2009

Engine

Engine TypeFour stroke, single cylinder, DOHC, 4 valves
Displacement30.5 cubic inches / 501 cc
Bore x Stroke97 x 67.8 mm
Compression Ratio12.9;1
Max Horsepower59.8 hp / 44 kW @ 8000 rpm
Max Torque56 ft-lb / 49 nm
Engine Management SystemInjection. Mikuni Digital Fuel Injection
Cooling SystemLiquid cooled

Performance

Top Speedn/a

Transmission

ClutchWet / Multiplate / 6 spd
Gearbox6 Speed
Gear Ratios1e 2.000 (28/14), 2nd 1.611 (29/18), 3th 1.333 (24/18), 4th 1.086 (25/23), 5th 0.920 (23/25), 6th 0.814 (22/27)
Final DriveChain

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeSteel single tube cradle (round, rectangular and ellipsoidal tubes); rear frame in light alloy
Front Suspension50mm Marzocchi Upside-Down telescopic hydraulic fork with advanced axle; compression and rebound stroke adjustment
Front Suspension Travel11.8 inches / 300 mm
Rear SuspensionSachs shock absorber Progressive Soft Damp type with single hydraulic shock absorber; spring preload adjustment, compression and rebound adjustment (compression stroke: double adjustment). 296mm wheel travel
Rear Suspension Travel11.7 inches / 296 mm

Wheels & Brakes

Front Tire Size90/90-21
Rear Tire Size120/90-18
Front BrakesSingle 260mm disc
Rear BrakesSingle 220mm disc

Dimension & Weights

Seat Height37.9 inches / 963 mm
Wheelbase58.7 inches / 1495 mm
Ground Clearance300 mm / 11.8 in
Fuel Tank Capacity1.9 US gallons / 7.2 L
Dry Weight112.0 kg / 246.9 lbs

Features

  • Steel single tube cradle frame
  • Rear frame in light alloy
  • 50mm Marzocchi Upside-Down telescopic hydraulic fork
  • Adjustable compression and rebound stroke
  • Improved riding position
  • Forward-shifted footrests
  • Adjustable steering angle
  • Brand new rear suspension
  • Fuel injected engines
  • Improved engine functionality and reliability
  • Semi-perimeter steel frame with oval and box tubes
  • New valve lifting system
  • New exhausts
  • New subframe
  • New rear suspension system
  • Wave type disc brakes
  • Engine protectors
  • Aluminium side stand
  • Digital display
  • Sachs shock absorber
