Husqvarna TE 449 (2011 - 2012)

The Husqvarna TE 449 is a revolutionary Enduro motorcycle that redefines the boundaries of performance and handling. Its sleek, aerodynamic design allows for unimpeded movement, while the advanced chassis layout, featuring a Coaxial Traction System, ensures maximum traction and stability.

The heart of the TE 449 is its potent DOHC engine, which delivers a unique combination of power and torque. Its advanced features include a 48mm UPSIDE-DOWN fork with adjustable compression and rebound, providing unparalleled control and precision.

The result is an exhilarating riding experience that combines raw power with exceptional agility and responsiveness. With its state-of-the-art technology and innovative design, the Husqvarna TE 449 is poised to dominate the Enduro scene. It is the ultimate competition machine.

Key Specifications

Engine Type	Four stroke, single cylinder, DOHC, 4 valves
Engine Capacity	27.4 cubic inches / 449 cc
Fuel Tank Capacity	2.4 US gallons / 9.2 L
Weight (Wet/Kerb)	249.1 lbs / 113 kg
Seat Height	37.9 inches / 963 mm

*n/a – information not provided by manufacturer

All Specifications

Make & Model

Model	Husqvarna TE 449
Year	2011 – 2012

Engine

Engine Type	Four stroke, single cylinder, DOHC, 4 valves
Displacement	27.4 cubic inches / 449 cc
Bore x Stroke	97 x 60.7 mm
Compression Ratio	12.0:1
Engine Management System	Electronic Fuel Injection
Cooling System	Liquid cooled
Exhaust	Full stainless steel system (silencer and pipes)

Performance

Top Speed

n/a

*n/a – information not provided by manufacturer

Transmission

Clutch	Wet, multiplate type; hydraulic control
Gearbox	6 Speed
Gear Ratios	1st 2.286 (32/14) 2nd 1.875 (30/16) 3rd 1.533 (23/15) 4th 1.250 (25/20) 5th 1.043 (24/23) 6th 0.917 (22/24)
Final Drive	Chain

Electrical & Electronics System

Starter

Electric & Kick

Chassis & Suspension

Frame Type	Double beam and double cradle high resistance Cr/Mo steel (round and elliptical section);Light alloy rear frame
Front Suspension	48mm Upside-Down” telescopic hydraulic fork with advanced axle; compression and rebound stroke adjustment
Front Suspension Travel	11.7 inches / 96 mm
Rear Suspension	.”KAYABA” Progressive link with single hydraulic shock absorber; spring preload adjustment, compression (high and low speed) and rebound adjustment
Rear Suspension Travel	11.7 inches / 296 mm
Rake	25.8
Trail	101 mm / 3.98 in

Wheels & Brakes

Front Tire Size	90/90-21
Rear Tire Size	140/80-18
Front Brakes	Single 260mm disc, Fixed disc, “Wave” type, with hydraulic control and double 24 piston floating caliper
Rear Brakes	Single 240mm disc, Fixed disc, “Wave” type, with hydraulic control and floating 26 piston caliper

Dimension & Weights

Seat Height	37.9 inches / 963 mm
Wheelbase	58.3 inches / 1480 mm
Fuel Tank Capacity	2.4 US gallons / 9.2 L
Wet (kerb/curb) Weight	249.1 lbs / 113 kg

Features

Double beam and double cradle high resistance Cr/Mo steel frame
Light alloy rear frame
48mm Upside-Down telescopic hydraulic fork with advanced axle
Compression and rebound stroke adjustment
Single piece side panel design for reduced snagging and improved maintenance
Long seat for free longitudinal movement
Mass centralisation to keep weight close to centre of gravity
Coaxial Traction System (CTS) for improved traction and handling
DOHC engine mounted close to centre of bike
Long and straight air intake path
Two part fuel tank design with 8.5 Litre capacity
Under seat fuel tank layout for improved airbox and air intake position
6 speed transmission for Enduro version
Optimised ignition timing with specific maps for different capacities and exhaust systems
Perimeter design chassis made of high strength steel tubing
New linkage mounted on top of alloy swing arm for rear suspension
Chain length remains constant during suspension movement

*We strive to provide the most comprehensive and accurate specifications possible. However, certain details may not be available if the manufacturer did not disclose them or if the information is no longer publicly accessible. If you find any discrepancy with any data on this site, please feel free to let us know at contact@throttlecraze.com
