Husqvarna TE 125 (2015 – 2016)

Husqvarna TE 125 (2015 - 2016)

The Husqvarna TE 125 is a masterclass in compact, high-performance motocross design. Its agile and lightweight chassis is perfectly tuned to the lively 2-stroke engine, delivering lightning-fast throttle response and razor-sharp handling.

The TE 125’s engine character is nothing short of exhilarating, with its agile and light chassis working in perfect harmony with the powerful 2-stroke unit. The addition of a contactless, controlled ignition system with digital timing adjustment further enhances the bike’s responsiveness and performance.

From its razor-sharp handling and precise gearbox to its class-leading brakes and high-performance capabilities, the Husqvarna TE 125 is the ultimate tool for future champions to hone their skills and for seasoned riders to experience the ultimate rush of adrenaline. It’s a machine that brings back the child in every man, and it’s sure to leave an indelible mark on the world of motocross.

Key Specifications

Engine TypeTwo stroke, single cylinder,with reed intake and exhaust control
Engine Capacity7.6 cubic inches / 124.8 cc
Fuel Tank Capacity2.5 US gallons / 9.5 L
Weight (Wet/Kerb)257.9 lbs / 117.0 kg
Seat Height37.8 inches / 960 mm
Husqvarna TE 125 (2015 - 2016)

All Specifications

Make & Model

ModelHusqvarna TE 125
Year2015 – 2016

Engine

Engine TypeTwo stroke, single cylinder,with reed intake and exhaust control
Displacement7.6 cubic inches / 124.8 cc
Bore x Stroke54.0 x 54.5 mm
Engine Management SystemKeihin 29 Carburettor
Lubrication SystemMixture oil lubrication
Cooling SystemLiquid cooled

Performance

Top Speedn/a

Transmission

ClutchWet multi-disc clutch / Magura hydraulics
Gearbox6 Speed
Gear Ratios1st 2.833 (34/12) 2nd 1.875 (30/16) 3rd 1.364 (30/22) 4th 1.143 (24/21) 5th 0.957 (22/23) 6th 0.840 (21/25
Final DriveChain. 520 X-Ring

Electrical & Electronics System

StarterElecteic

Chassis & Suspension

Frame TypeCentral tube frame made of chrome molybdenum steel tubing
Front SuspensionWP Suspension Up Side Down 4CS
Front Suspension Travel11.8 inches / 300 mm
Rear SuspensionWP Monoshock with linkage
Rear Suspension Travel12.9 inches / 330 mm
Rake26.5

Wheels & Brakes

Front Tire Size90/90-21
Rear Tire Size120/80-18
Front BrakesSingle 260mm disc 4 piston caliper
Rear BrakesSingle 220mm disc 2 piston caliper

Dimension & Weights

Seat Height37.8 inches / 960 mm
Wheelbase57.9 inches / 1471 mm
Ground Clearance355 mm / 14.0 in
Fuel Tank Capacity2.5 US gallons / 9.5 L
Wet (kerb/curb) Weight257.9 lbs / 117.0 kg
Dry Weight96.0 kg / 211.6 lbs

Features

  • Contactless, controlled, fully electronic ignition system
  • Digital ignition timing adjustment
  • Kokusan An agile and light chassis
  • Lightning fast throttle response
  • Class-leading brakes
  • Smooth and precise gearbox
  • New 4CS fork with improved damping
  • New 22mm front axle for reduced unsprung weight
  • New linkage geometry for optimized rising rate
  • New shock with increased stroke and new setting
  • Rear subframe reinforcement for improved airbox sealing
  • New fork protectors for easier replacement and maintenance
  • Improved handguards for better impact resistance
  • New Neken handlebar and bar pad
  • New seat cover with better grip and durability
  • New Dunlop MX52 tyres
  • New clutch basket with weight-saving design and new clutch springs
  • New O-rings on the oil pump suction screen for 4-stroke engines
  • New swingarm on the TC 85 with weight reduction and redesigned chain guide
  • New ignition curve on the TC 125 for safety against detonation
