Husqvarna Svartpilen 801 (2024)

The 2024 Husqvarna Svartpilen 801 is a masterclass in urban motorcycling, blending performance, agility, and style with unparalleled versatility. Its compact and powerful parallel-twin engine, nestled within a perfectly balanced tubular frame, delivers a thrilling ride experience.

Ridden with a keen sense of engagement and intuition, the Svartpilen 801 allows each rider to set their own tone for navigating city streets. Its refined ergonomics, adjustable WP suspension, and state-of-the-art electronic aids come together to create a truly exceptional machine.

With a peak power output of 105 horsepower and a power-to-weight ratio that’s as impressive as it is well-balanced, the Svartpilen 801 is an exhilarating companion for any ride, whether it’s a daily commute or a spirited weekend adventure.

Key Specifications

Engine Type	Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
Engine Capacity	799 cc / 48.7 cu in
Max Power	105 hp / 77 kW @ 9250 rpm
Max Torque	64.2 ft-lb / 87 nm
Fuel Tank Capacity	3.7 US gallons / 14.0 L
Weight (Wet/Kerb)	421 lbs / 190 kg
Seat Height	32.2 inches / 820 mm

*n/a – information not provided by manufacturer

All Specifications

Make & Model

Model	Husqvarna Svartpilen 801
Year	2024

Engine

Engine Type	Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
Displacement	799 cc / 48.7 cu in
Bore x Stroke	88 x 65.7 mm
Compression Ratio	12.5:1
Max Horsepower	105 hp / 77 kW @ 9250 rpm
Max Torque	64.2 ft-lb / 87 nm
Engine Management System	DKKDellorto (Throttle body 46mm)
Lubrication System	Forced oil lubrication with 2 oil pumps
Cooling System	Liquid / oil heat exchanger
Exhaust	Stainless steel primary and secondary silencer

Performance

Top Speed

n/a

*n/a – information not provided by manufacturer

Transmission

Clutch	PASCslipper clutch, mechanically operated
Gearbox	6 Speed
Final Drive	Chain X-Ring

Electrical & Electronics System

Starter	Electric
ABS	Bosch 9.3 MP (incl. Cornering-ABS and Supermoto mode, disengageable)

Chassis & Suspension

Frame Type	Chromium-Molybdenum-Steel frame using the engine as stressed element, powder coated
Front Suspension	43 mm WP APEX USD forks, Rebound and preload adjustable
Front Suspension Travel	5.5 inches / 140 mm
Rear Suspension	WP APEX -Monoshock
Rear Suspension Travel	5.9 inches / 150 mm
Rake	24.5
Trail	65.5
Handlebar	Forged aluminium triple clamps

Wheels & Brakes

Wheels	Cast aluminium
Front Wheel/Rim Size	3.50 x 17 in
Front Tire Size	120/70-R17 Pirelli MT 60 RS
Rear Wheel/Rim Size	5.50 x 17 in
Rear Tire Size	180/55-R17 Pirelli MT 60 RS
Front Brakes	Single 300 mm disc,2 x radially mounted 4 pistonBrembo caliper
Rear Brakes	Single 240 mm disc, Brembo 2 piston, floating caliper
ABS	Bosch 9.3 MP (incl. Cornering-ABS and Supermoto mode, disengageable)

Dimension & Weights

Seat Height	32.2 inches / 820 mm
Wheelbase	54.6 inches / 1388 mm
Ground Clearance	174 mm / 6.8 in
Fuel Tank Capacity	3.7 US gallons / 14.0 L
Wet (kerb/curb) Weight	421 lbs / 190 kg
Dry Weight	181 kg / 399 lbs

Features

New compact and powerful parallel-twin engine
799 cc displacement
Peak power output of 105 hp
Light weight of 181 kg
Chromium-molybdenum tubular steel frame
Adjustable WP APEX suspension
140 mm fork travel
150 mm shock travel
Power Assist Slipper Clutch (PASC) system
Easy Shift
Pirelli MT60 RS tyres
17-inch wheels
Slimline ergonomic bodywork
Two-piece seat
LED lights
Aluminium handlebars
State-of-the-art electronic aids
Adjustable Motorcycle Traction Control (MTC)
ABS
Street, Rain, and Sport ride modes
Dynamic Pack with Motor Slip Regulation (MSR) and Anti-Wheelie mode
J.Juan brake system
