The Husqvarna Svartpilen 401 is a masterclass in modern motorcycling, where classic design sensibilities meet cutting-edge technology. At its heart lies a potent, 373cc single-cylinder engine producing 44hp, effortlessly navigating both urban jungles and open roads.
Its dynamic chassis, inviting dimensions, and low weight create an engaging ride, while WP suspension and ByBre brakes with Bosch ABS ensure exceptional handling and stopping power.
The trellis frame, made from high-strength steel, is the unsung hero of the Svartpilen’s character and agility, working in harmony with the WP suspension to deliver a comfortable and confident feel. With its state-of-the-art Easy Shift function, ride-by-wire throttle, and high-quality components, the Svartpilen 401 is an exhilarating ride that truly lives up to its progressive design philosophy, making it a thrilling companion for any motorcyclist.
Key Specifications
Engine Type
Four stroke, single cylinder, DOHC with cam levers, 4 valves
Engine Capacity
22.8 cubic inches / 373.2 cc
Max Power
44 hp / 32 kW @ 9000 rpm
Max Torque
27.3 ft-lb / 37 nm
Fuel Tank Capacity
2.5 US gallons / 9.5 L
Seat Height
32.8 inches / 835 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Husqvarna Svartpilen 401
Year
2022
Engine
Engine Type
Four stroke, single cylinder, DOHC with cam levers, 4 valves
Displacement
22.8 cubic inches / 373.2 cc
Bore x Stroke
89 x 60 mm
Compression Ratio
12.6:1
Max Horsepower
44 hp / 32 kW @ 9000 rpm
Max Torque
27.3 ft-lb / 37 nm
Engine Management System
Bosch EFI (throttle body 46 mm)
Lubrication System
Wet sump with 2 oil pumps
Cooling System
Liquid cooled
Exhaust
Stainless steel / Aluminium silencer with regulated catalyticconverter
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Multi disc slipper clutch
Gearbox
6 Speed
Primary Drive Ratio
30:80
Final Drive
Chain, X-Ring 5/8 x 1/4″
Electrical & Electronics System
Starter
Electric
ABS
Two channel Bosch 10.1MB
Chassis & Suspension
Frame Type
Steel trellis frame, powder coated
Front Suspension
43mm WP APEX upside-down forks, with compression rebound adjustability
Front Suspension Travel
5.6 inches / 142 mm
Rear Suspension
WP APEX monoshock with preload adjustability
Rear Suspension Travel
5.6 inches / 142 mm
Rake
25
Trail
95 mm / 3.7 in
Wheels & Brakes
Wheels
Spoked wheels with aluminium rims
Front Wheel/Rim Size
3.00 x 17
Front Tire Size
110/70-R17 Pirelli Scorpion Rally STR
Rear Tire Size
150/60-R17 Pirelli Scorpion Rally STR
Front Brakes
Single 320mm disc, ByBre 4 piston caliper
Rear Brakes
Single 230mm disc, ByBre, single piston, floating caliper
ABS
Two channel Bosch 10.1MB
Dimension & Weights
Seat Height
32.8 inches / 835 mm
Wheelbase
53.4 inches / 15.5 mm
Ground Clearance
145 mm / 5.6 in
Fuel Tank Capacity
2.5 US gallons / 9.5 L
Dry Weight
152 kg / 335.6 lbs
Features
44 hp single-cylinder EURO 5-compliant engine
373 cc engine
Dynamic chassis
Low weight
WP suspension
ByBre brakes
Bosch ABS
Trellis frame
High-strength steel frame
Hydro-formed tubes
Robot welding
Bolt-on subframe
Pin-jointed swingarm
WP monoshock
WP APEX 43 mm open-cartridge forks
Split damping function
Adjustable compression and rebound
Easy Shift function
Ride-by-wire throttle
State-of-the-art technology fitted standard
