The Husqvarna Svartpilen 401 is a rugged and progressive motorcycle that embodies the spirit of urban exploration. Its punchy 44 hp single-cylinder engine provides the perfect blend of power and agility, making it an absolute master of navigating tight city streets.
With a lightweight and robust chromium molybdenum trellis frame, combined with high-performance WP APEX suspension and a commanding riding position, the Svartpilen 401 offers a dynamic riding experience that’s hard to beat.
The modern design is enhanced by a new, quality painted finish with subtle silver accents, while the bolt-on subframe has been optimised and extended by 40 mm for improved comfort when accompanied by a pillion rider. Perfectly suited for both urban environments and out-of-town riding, the Svartpilen 401 is an unbeatable companion for any rider.
Key Specifications
Engine Type
Four stroke, single cylinder, DOHC, 4 valve
Engine Capacity
22.8 cubic inches / 373.2 cc
Max Power
43 hp / 32 kW @ 9000 rpm
Max Torque
27.3 ft-lb / 37 nm
Fuel Tank Capacity
2.5 US gallons / 9.5 L
Seat Height
32.8 inches / 835 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Husqvarna Svartpilen 401
Year
2020 – 2021
Engine
Engine Type
Four stroke, single cylinder, DOHC, 4 valve
Displacement
22.8 cubic inches / 373.2 cc
Bore x Stroke
89 x 60 mm
Compression Ratio
12.6:1
Max Horsepower
43 hp / 32 kW @ 9000 rpm
Max Torque
27.3 ft-lb / 37 nm
Engine Management System
Fuel injection
Lubrication System
Wet sump
Cooling System
Liquid cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
PASC antihopping clutch, mechanically operated
Gearbox
6 Speed
Final Drive
Chain, X-Ring 5/8 x 1/4″
Electrical & Electronics System
Starter
Electric
ABS
Bosch 9M+ two-channel ABS (disengageable)
Chassis & Suspension
Frame Type
Steel trellis frame, powder coated
Front Suspension
43mm WP upside-down forks
Front Suspension Travel
5.5 inches / 142 mm
Rear Suspension
WP monoshock
Rear Suspension Travel
5.9 inches / 150 mm
Rake
25
Trail
95 mm / 3.7 in
Wheels & Brakes
Front Wheel/Rim Size
Wire-spoked w/ aluminum rims 3.00 x 17
Front Tire Size
110/70 – 17 Pirelli Scorpion Rally STR
Rear Tire Size
150/60 – 17 Pirelli Scorpion Rally STR
Front Brakes
Single 320mm disc, 4 piston floating calliper
Rear Brakes
Single 230mm disc 1 piston floating calliper
ABS
Bosch 9M+ two-channel ABS (disengageable)
Dimension & Weights
Seat Height
32.8 inches / 835 mm
Wheelbase
53.4 inches / 15.5 mm
Ground Clearance
145 mm / 5.6 in
Fuel Tank Capacity
2.5 US gallons / 9.5 L
Dry Weight
152 kg / 335.6 lbs
Features
44 hp single cylinder engine
Chromium molybdenum trellis frame
Low weight of 152 kg without fuel
High-performance WP APEX suspension
Commanding riding position
Bolt-on subframe with 40 mm extension for pillion comfort
Quality painted finish with subtle silver accents
373 cc single cylinder engine
Dynamic chassis
Accessible overall size and low weight
New paint finish and graphics
75 hp high-performance 692 cc single cylinder engine
Lightweight chassis
New spoked wheels
CNC machined footrests
Standard pillion seat cover
Upright riding position
Refined fuelling for exceptional throttle response
40 mm extended subframe for pillion comfort
Pillion seat cover
