Husqvarna Svartpilen (2019 – 2020)

Husqvarna Svartpilen (2019 - 2020)

The Husqvarna Svartpilen is a testament to the raw, unbridled spirit of motorcycling. Its rugged, flat track-inspired design exudes a timeless appeal, transporting riders back to the early days of street motorcycling. Beneath its minimalist exterior lies a powerful 692.7cc liquid-cooled single-cylinder engine, producing 75 horsepower and 72 Nm of torque.

Riding the Svartpilen is an exhilarating experience, with immediate and refined power delivery courtesy of its ride-by-wire system and standard traction control. The electronic fuel injection system is precision-tuned, offering optimal performance and efficiency.

This masterclass in engineering is further underscored by the inclusion of a standard up & down easy shift, ensuring seamless gear changes. With premium reliability and convenience thanks to a 10,000 km service interval, the Svartpilen is the ultimate urban explorer.

Key Specifications

Engine TypeFour stroke, single cylinder, SOHC, 4 valves with intake cam levers and exhaust rocker arm
Engine Capacity692.7 cc / 42.27 cu in
Max Power55 kw / 75 hp
Max Torque71Nm / 7.24 kgf-m / 52.4 ft-lb @ 6750 rpm
Fuel Tank Capacity3.17 US gallons / 12.0 L
Seat Height32.9 inches / 835 mm
Husqvarna Svartpilen (2019 - 2020)

All Specifications

Make & Model

ModelHusqvarna Svartpilen
Year2019 – 2020

Engine

Engine TypeFour stroke, single cylinder, SOHC, 4 valves with intake cam levers and exhaust rocker arm
Displacement692.7 cc / 42.27 cu in
Bore x Stroke105 x 80 mm
Compression Ratio12.8:1
Max Horsepower55 kw / 75 hp
Max Torque71Nm / 7.24 kgf-m / 52.4 ft-lb @ 6750 rpm
Engine Management SystemKeihin EFI, 50mm throttle body
Lubrication SystemPressure lubrication with 2 oil pumps
Cooling SystemLiquid cooling
ExhaustStainless steel primary and secondary silencer

Performance

Top Speedn/a

Transmission

ClutchAPTC slipper clutch, hydraulically actuated
Gearbox6 Speed
Final DriveChain X-Ring 5/8 x 1/4″

Electrical & Electronics System

StarterElectric
ABSABS Bosch 9M+ Two Channel

Chassis & Suspension

Frame TypeChromium-Molybdenum-Steel trellis frame, powder coated, aluminium
Front Suspension43 mm WP-USD forks
Front Suspension Travel5.9 inches / 150 mm
Rear SuspensionWP-Monoshock with Pro-Lever linkage
Rear Suspension Travel5.9 inches / 150 mm
Trail65
HandlebarForged aluminium triple clamps

Wheels & Brakes

Front Tire SizePirelli MT60 RS 18 in
Rear Tire SizePirelliMT60 RS 17 in
Front BrakesSingle 320 mm disc,4 pistonBrembo caliper
Rear BrakesSingle 240 mm disc, Brembo single piston, floating caliper
ABSABS Bosch 9M+ Two Channel

Dimension & Weights

Seat Height32.9 inches / 835 mm
WheelbaseNA
Ground Clearance164 mm / 6.5 in
Fuel Tank Capacity3.17 US gallons / 12.0 L
Dry Weight158.5 kg / 349.4 lbs

Features

  • 692.7 cc liquid cooled, single-cylinder engine
  • 55 kW (75 hp) peak horsepower
  • 72 Nm of torque at 6750 rpm
  • Electronic fuel injection with ride-by-wire system
  • Standard traction control system
  • Up & down easy shift
  • 10,000 km service interval
  • Steel pre-silencer exhaust system
  • Final silencer with black finish
  • WP suspension with upside down 43 mm forks
  • Split damping function on front fork
  • Monoshock rear suspension
  • Linkage to swingarm
  • Hydraulic BREMBO disk brake callipers
  • 320 mm front and 240 mm rear perforated steel discs
  • State-of-the-art BOSCH ABS system
  • Premium reliability and efficiency ensured by innovative production processes and high-quality materials
  • Long-travel suspension for urban riding
  • Flat track-inspired design
