The Husqvarna FE 501S is the ultimate enduro machine, now street-legal and ready to take on the world. This powerhouse of a motorcycle boasts an unbeatable combination of extreme power, razor-sharp handling, and go-anywhere versatility.
Its potent 510.4cc SOHC engine is the epitome of tractable power, delivering maximum performance with ease. The 6-speed gearbox and hydraulic clutch ensure seamless shifting, while class-leading Brembo brakes provide unparalleled stopping power.
The FE 501S’s engine is a marvel of engineering, with a compact layout that maximizes packaging efficiency. The die-cast production process reduces weight while maintaining strength, and the cylinder head features a single overhead cam and titanium intake valves for optimal performance.
The result is a machine that is as easy to use as it is exhilarating to ride, with a smooth and efficient power delivery that belies its incredible power output. Whether carving up twisties or tackling the toughest terrain, the Husqvarna FE 501S is the ultimate riding experience.
Key Specifications
Engine Type
Four stroke. single cylinder. SOHC. 4 valve per cylinder
Engine Capacity
510.4 cc /31.1cu in
Max Power
45 hp / 32.8 kW
Max Torque
Nm / ft-lb @ rpm
Fuel Tank Capacity
2.8 US gallons / 9.5 L
Seat Height
38.2 inches / 970 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Husqvarna FE 501S
Year
2015 – 2016
Engine
Engine Type
Four stroke. single cylinder. SOHC. 4 valve per cylinder
Displacement
510.4 cc /31.1cu in
Bore x Stroke
95 x 72.0 mm
Compression Ratio
12.8:1.
Max Horsepower
45 hp / 32.8 kW
Max Torque
Nm / ft-lb @ rpm
Engine Management System
Keihin electronic fuel injection and 42mm throttle body
Lubrication System
Forced oil lubrication with 2 Eaton pumps
Cooling System
Liquid cooling system, continuous circulation of cooling liquid with water pump
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet multi-disc clutch DDS / Brembo hydraulics
Gearbox
6 speed, claw shifted
Primary Drive Ratio
24:73
Secondary Drive Ratio
14:52 (13:52)
Final Drive
Chain 520 X-Ring
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Frame Type
Central tube frame made of chrome molybdenum steel tubing
Front Suspension
WP Suspension Up Side Down 4CS forks.
Front Suspension Travel
11.8 inches / 300 mm
Rear Suspension
WP Monoshock with linkage
Rear Suspension Travel
13.0 inches / 330 mm
Trail
107 mm / 4.2 in
Wheels & Brakes
Front Tire Size
90/90-21
Rear Tire Size
140/90-18
Front Brakes
Single 260 mm with 4 pot brake caliper
Rear Brakes
Single 220 mm with 1 pot brake caliper
Dimension & Weights
Seat Height
38.2 inches / 970 mm
Wheelbase
58.3 inches / 148210 mm
Ground Clearance
345 mm / 13.6 in
Fuel Tank Capacity
2.8 US gallons / 9.5 L
Dry Weight
113.5 kg / 250.2 lbs
Features
510.4cc SOHC engine
Electric starting
6-speed gearbox with hydraulic clutch
Brembo brakes
Compact engine layout
Thinner wall thickness die-cast production procedure
Single overhead cam
Lightweight titanium intake valves
Steel exhaust valves
Knig bridge-box-type piston
Multifunctional counter balance shaft
High-tensile strength crankshaft and con rod
135 hours before con rod and crank pin replacement
Keihin electronic fuel injection
42mm throttle body
Retro-fit kick-starter option
Lightweight chromium molybdenum frame
Precise longitudinal flex in frame
