The Husqvarna FE 501 is a powerhouse of an enduro bike, boasting the most potent engine in the Husqvarna range. With a 510.4 cc power plant weighing in at just 64.8 lbs, this bike delivers colossal performance in any condition, thanks in part to its lightweight 6-speed transmission and DDS clutch.
A key highlight of the FE 501 is its ability to minimize vibration, thanks to a counter balancer shaft and a compact SOHC cylinder head that’s been redesigned to be 15 mm lower and 500 g lighter. This not only improves handling but also enhances bottom-end performance and responsiveness.
The FE 501’s engine is a masterclass in weight reduction and optimized efficiency, with improvements to the cylinder and piston setup, including a new lightweight aluminum cylinder and a Konig forged bridge-box-type piston. This combination produces remarkably little oscillating mass, significantly reducing vibration and increasing rider comfort.
The FE 501 is a testament to Husqvarna’s commitment to quality and craftsmanship, with high-quality finishes and premium components throughout. Whether you’re carving through tight trails or tackling the toughest terrain, the Husqvarna FE 501 is an enduro bike that’s sure to leave you grinning from ear to ear, and always ready to tackle the next adventure.
Key Specifications
Engine Type
Four stroke. single cylinder. SOHC. 4 valve per cylinder
Engine Capacity
510.4 cc / 31.1 cu in
Max Power
45 hp / 32.8 kW
Max Torque
Nm / ft-lb @ rpm
Fuel Tank Capacity
2.25 US gallons / 8.5 L
Seat Height
38.2 inches / 970 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Husqvarna FE 501
Year
2020 – 2021
Engine
Engine Type
Four stroke. single cylinder. SOHC. 4 valve per cylinder
Displacement
510.4 cc / 31.1 cu in
Bore x Stroke
95 x 72.0 mm
Compression Ratio
12.7:1.
Max Horsepower
45 hp / 32.8 kW
Max Torque
Nm / ft-lb @ rpm
Engine Management System
Keihin electronic fuel injection and 42mm throttle body
Lubrication System
Forced oil lubrication with 2 Eaton pumps
Cooling System
Liquid cooling system, continuous circulation of cooling liquid with water pump
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet, DDS multi-disc clutch, Magura hydraulics
Gearbox
6 Speed, claw shifted
Primary Drive Ratio
31:76
Secondary Drive Ratio
14:52 (13:52)
Final Drive
Chain 520 X-Ring
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Frame Type
Frame design 25CrMo4 steel central-tube
Front Suspension
WP-USD Xplor 48 with preload adjuster
Front Suspension Travel
11.8 inches / 300 mm
Rear Suspension
WP shock absorber with linkage
Rear Suspension Travel
11.8 inches / 300 mm
Trail
107 mm / 4.2 in
Wheels & Brakes
Front Tire Size
90/90-21
Rear Tire Size
140/80-18
Front Brakes
Single 260 mm with 4 pot brake caliper
Rear Brakes
Single 220 mm with 1 pot brake caliper
Dimension & Weights
Seat Height
38.2 inches / 970 mm
Wheelbase
58.3 inches / 148210 mm
Ground Clearance
370 mm / 14.6 in
Fuel Tank Capacity
2.25 US gallons / 8.5 L
Dry Weight
111 kg / 244.7 lbs
Features
Most powerful engine in the Husqvarna enduro range
510.4 cc power plant
Weighs 64.8 lbs
Electric starter
Counter balancer shaft
6-speed transmission
DDS (Dampened Diaphragm Steel) clutch
Compact SOHC cylinder head
15 mm lower and 500g lighter
Improved handling and bottom end performance
New rocker arms with 40 mm titanium intake valves
New rocker arms with 33 mm steel exhaust valves
Improved cam surface and DLC coating
Shorter low-friction chain guides
Increased compression ratio from 11.7:1 to 12.75:1
Lightweight aluminum cylinder
New lightweight Konig forged bridge-box-type piston
10% lighter piston pin
High-pressure die cast crankcases
Centralized masses for a lightweight handling feel
Increased longitudinal and torsional rigidity in the frame
Forged aluminum cylinder head mountings
Standard frame protectors
High strength aluminum radiators with CFD optimized air flow
