The Husqvarna 701 Enduro is a machine that embodies the very essence of its iconic brand. Built from the ground up to deliver unparalleled performance, this Swedish-inspired motorcycle combines state-of-the-art equipment with a unique design that is as functional as it is stylish.
At its heart lies a potent 690cc engine, featuring a double spark plug ignition, ride-by-wire throttle, and selectable engine maps, which together provide a perfectly linear power delivery. With its crisp throttle response, this engine is a joy to ride, whether tackling the toughest off-road terrain or navigating the urban jungle.
From its competition-level WP suspension to its cutting-edge ABS system, every aspect of the 701 Enduro has been carefully crafted to provide the ultimate riding experience. With its lightweight aluminum swingarm, adjustable WP rear shock, and polyamide self-supporting rear subframe, this motorcycle offers the perfect blend of agility, control, and stability.
Whether you’re a seasoned enduro veteran or a newcomer to the world of off-road riding, the Husqvarna 701 Enduro is an unbeatable companion that will inspire confidence and excitement with every ride, making it the ultimate machine for anyone who demands the best.
Key Specifications
Engine Type
Four stroke, single cylinder, SOHC, 4 valves
Engine Capacity
690 cc / 42.1 cu in
Max Power
49 kw / 67 hp
Max Torque
44.2 ft-lb / 68 nm
Fuel Tank Capacity
3.4 US gallons / 13.5 L
Seat Height
35.8 inches / 910 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Husqvarna 701 Enduro
Year
2016 – 2017
Engine
Engine Type
Four stroke, single cylinder, SOHC, 4 valves
Displacement
690 cc / 42.1 cu in
Bore x Stroke
102 x 84.5 mm
Compression Ratio
12.6:1
Max Horsepower
49 kw / 67 hp
Max Torque
44.2 ft-lb / 68 nm
Engine Management System
Keihin EMS with RBW, twin ignition
Cooling System
Liquid cooling
Exhaust
Stainless steel silencer with regulated catalytic converter
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
APTC slipper clutch, hydraulically operated
Gearbox
Constant mesh, 6-speed
Final Drive
Chain X-Ring 5/8 x 1/4
Electrical & Electronics System
Battery
12V 8.6Ah
Starter
Electric
ABS
ABS Bosch 9M+ Two Channel (disengageable, supermoto mode)
Chassis & Suspension
Frame Type
Chrome-moly tubular space frame, powder-coated
Front Suspension
48mm WP 4CS cartridge fork; compression and rebound adjustable
Front Suspension Travel
10.8 inches / 275 mm
Rear Suspension
WP single shock; compression and rebound adjustable
Rear Suspension Travel
10.8 inches / 275 mm
Rake
27
Trail
111.7 mm / 4.4 in
Handlebar
Aluminium, tapered, 28/22 mm
Wheels & Brakes
Front Wheel/Rim Size
Spoked wheels with aluminium tubeless rims 1.85 x 21
Front Tire Size
90/90 – 21
Rear Wheel/Rim Size
Spoked wheels with aluminium tubeless rims 2.50 x 18
Rear Tire Size
140/80 -18
Front Brakes
Single 300 mm disc, Brembo four piston, radially bolted caliper
Rear Brakes
Single 240 mm disc, Brembo single piston, floating caliper
ABS
ABS Bosch 9M+ Two Channel (disengageable, supermoto mode)
Dimension & Weights
Seat Height
35.8 inches / 910 mm
Wheelbase
59.2 inches / 15 mm
Ground Clearance
280 mm / 11.0 in
Fuel Tank Capacity
3.4 US gallons / 13.5 L
Dry Weight
145 kg / 320 lbs
Features
690 cc single-cylinder engine
Double spark plug ignition
Selectable engine maps
Ride-by-wire throttle
Active crankcase evacuation
Forced lubrication system
High-tech engine design and electronics
Chromium-molybdenum trellis frame
WP 4CS fork
WP rear shock
Extremely low-weight aluminum swingarm
Polyamide self-supporting rear subframe
Integrated 3.44 gal fuel tank
Keihin 46mm electronic fuel injection
Switchable ABS
Off-road mode on ABS
APTC slipper clutch
Switchable engine maps
