Harley Davidson XR 1200X (2012)

The 2012 Harley-Davidson XR 1200X takes the sporty XR platform to new heights with a finely tuned suspension system.

Fully-adjustable Showa front and rear suspension components allow riders to customize their ride for optimal performance. Paired with high-compression, 1200cc Evolution V-Twin engine, this motorcycle delivers exceptional street performance.

The XR 1200X’s aggressive styling is inspired by the legendary Harley-Davidson XR750, a nod to the brand’s rich racing heritage. Wide flat-track bars and rearset footpegs provide an assertive riding position, while blacked-out powertrain and exhaust add to the bike’s menacing look.

From its responsive engine to its sport-tuned suspension, every detail of the XR 1200X is designed to deliver a thrilling ride experience. With its unique blend of style and performance, this motorcycle is poised to dominate any twisty road it encounters, making it an absolute joy to ride from the very first mile.

Key Specifications

Engine Type	Four stroke, 45 V-Twin, OHV, 2 valves per cylinder.
Engine Capacity	73.3 cubic inches / 1202 cc
Max Power	67 kw / 91 hp
Max Torque	73.7 ft-lb / 100 nm
Fuel Tank Capacity	13.5 Litres / 3.4 gal
Seat Height	29.1 inches / 741.6 mm

*n/a – information not provided by manufacturer

All Specifications

Make & Model

Model	Harley Davidson XR 1200X
Year	2012

Engine

Engine Type	Four stroke, 45 V-Twin, OHV, 2 valves per cylinder.
Displacement	73.3 cubic inches / 1202 cc
Bore x Stroke	88.9 x 96.8mm
Compression Ratio	10.0:1
Max Horsepower	67 kw / 91 hp
Max Torque	73.7 ft-lb / 100 nm
Engine Management System	Electronic sequential port fuel-injection
Lubrication System	Dry sump
Cooling System	Air cooled,

Performance

Top Speed

n/a

*n/a – information not provided by manufacturer

Transmission

Clutch	Cable-operated multiplate wet clutch.
Gearbox	5 Speed
Gear Ratios	1st 10.78 2nd 7.702 3rd 5.728 4th 4.748 5th 4.071
Final Drive	Belt

Electrical & Electronics System

Starter

Electric

Chassis & Suspension

Frame Type	Mild steel tubular frame; circular sections; cast junctions
Front Suspension	43mm Showa inverted cartridge forks.
Rear Suspension	Dual Showa hydraulic shock absorbers adjustable for preload.
Rake	29.3
Trail	130 mm / 5.1 in

Wheels & Brakes

Front Wheel/Rim Size	Black, 3-Spoke Cast Aluminum
Front Tire Size	120/70 -18
Rear Wheel/Rim Size	Black, 3-Spoke Cast Aluminum
Rear Tire Size	190/50 -17
Front Brakes	Single 292mm discs Nissin 4 piston calipers
Rear Brakes	Single 260mm disc Nissin 1 piston calipers

Dimension & Weights

Seat Height	29.1 inches / 741.6 mm
Wheelbase	59.8 inches / 1518.9 mm
Ground Clearance	147.3 mm / 5.8 in
Fuel Tank Capacity	13.5 Litres / 3.4 gal
Dry Weight	260 kg / 573 lbs

Features

Fully-adjustable Showa front and rear suspension components
High-compression 1200cc Evolution V-Twin engine
Enhanced front brakes with Nissin full-floating calipers
Adjustable rebound, compression damping, and spring preload on Showa Big Piston Front Fork
Adjustable Showa rear shocks for rebound, compression, and spring preload
Wide flat-track bars for active control
Rearset footpegs for optimal riding position
Blacked-out powertrain and exhaust
Revised tank graphics
Black wheels with orange rim pinstripe
Upside-down forks
Matt black tail, tank, and mudguards for aggressive look
Sport-tuned Showa piggyback suspension for enhanced performance and firmer handling
