In a milestone moment for Harley-Davidson Motor Co., the new XR1000 street racer made its official debut at Daytona Beach in ’83. The return of an H-D team to road racing was met with triumph as they scored two crushing victories on variations of this very bike.
The XR1000’s impressive competition credentials were evident from the start, thanks to its direct lineage from the dominant US dirt-track racing machine – the XR750. This bike has ruled its class for over a decade, and its road-going counterpart is finally here.
As you swing into the saddle, the XR1000 comes alive with its characteristic V-twin engine roar, providing an exhilarating riding experience that’s as raw as it is refined. With its powerful overhead-valve design and precision-crafted components, this bike delivers a thrilling combination of speed, agility, and style.
And now, after years of anticipation, the wait is finally over – Harley-Davidson has unleashed the XR1000 on the road, putting its legendary competition credentials within reach of any serious motorcyclist.
Key Specifications
Engine Type
Four stroke, 45 V-Twin, OHV, 2 valves per cylinder
Engine Capacity
60.8 cubic inches / 998 cc
Max Power
70 hp / 52.6 kW @ 5600 rpm
Max Torque
48 lb-ft / 65 Nm @ 4400 rpm
Fuel Tank Capacity
2.5 US gallons / 9.5 L
Weight (Wet/Kerb)
509.3 lbs / 231.0 kg
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Harley Davidson XR 1000
Year
1984
Engine
Engine Type
Four stroke, 45 V-Twin, OHV, 2 valves per cylinder
Displacement
60.8 cubic inches / 998 cc
Bore x Stroke
81 x 96.8 mm
Compression Ratio
9.0;1
Max Horsepower
70 hp / 52.6 kW @ 5600 rpm
Max Torque
48 lb-ft / 65 Nm @ 4400 rpm
Engine Management System
2X 36mm Dell’Orto carburetor
Cooling System
Air cooled
Performance
Top Speed
185 km/h / 115 mph
*n/a – information not provided by manufacturer
Transmission
Gearbox
4 Speed
Final Drive
Chain
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Front Suspension
Telescopic forks
Front Suspension Travel
6.8 inches / 175 mm
Rear Suspension
Dual shocks, Swing arm
Rear Suspension Travel
3.9 inches / 100 mm
Wheels & Brakes
Front Tire Size
100/90 V19
Rear Tire Size
130/90 V16
Front Brakes
2X 292mm discs
Rear Brakes
Single 292mm disc
Dimension & Weights
Fuel Tank Capacity
2.5 US gallons / 9.5 L
Wet (kerb/curb) Weight
509.3 lbs / 231.0 kg
Dry Weight
228 kg / 502.6 lbs
Features
Twin-cylinder engine with overhead valves
Derived from the successful XR750 dirt-track model
1000cc displacement
Road-going version of a competition motorcycle
Brakes, lights, and alternator added to a miler chassis
Alloy-barreled version available
Iron-jug engine option also available
Engine modifications for improved performance
Suspension upgraded for road riding
New frame design for better handling
Improved ergonomics and rider comfort
Higher ground clearance
Larger fuel tank capacity
Dual carburetors or single electronic fuel injection
5-speed transmission with overdrive
Hydraulic front brake with floating disc
Adjustable rear shock absorber
