The 1973 and 1974 Harley-Davidson XLCH 1000 Sportster – a true legend in the world of motorcycles. This iconic bike was built for those who crave raw power, aggressive styling, and unbridled freedom on the open road.
At its heart lies an air-cooled, single-cylinder, OHV engine that pumps out a generous 53 horsepower at 6,000 rpm. The XLCH’s exhaust system roars to life with each twist of the throttle, imbuing riders with an unwavering sense of excitement and exhilaration.
Behind the bars, the Sportster offers a commanding riding position, allowing its pilot to dominate any road or terrain. Its robust front fork soaks up bumps and potholes, while its wide 16-inch rear tire grips the asphalt with tenacious hold.
The result is an unforgettable experience that’s as much about the ride itself as it is about the journey – a symphony of engine growl, wind rush, and unadulterated joy that leaves riders yearning for more.
Key Specifications
Engine Type
Four stroke, 45 V-Twin, OHV, 2 valves per cylinder.
Engine Capacity
60.8 cubic inches / 997 cc
Max Power
57 hp / 41.6 kW @6200 rpm
Max Torque
60 lb ft / 81 Nm @ 3500 rpm
Fuel Tank Capacity
2.3 US gallons / 9.0 L
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Harley Davidson XLCH 1000 Sportster
Year
1973 – 74
Engine
Engine Type
Four stroke, 45 V-Twin, OHV, 2 valves per cylinder.
Displacement
60.8 cubic inches / 997 cc
Bore x Stroke
81 x 96.8 mm
Compression Ratio
9.0:1
Max Horsepower
57 hp / 41.6 kW @6200 rpm
Max Torque
60 lb ft / 81 Nm @ 3500 rpm
Engine Management System
38mm Keihin carburetor
Lubrication System
Dry sump
Cooling System
Air cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet, multiple discs, cable operated
Gearbox
4 Speed
Final Drive
Chain
Electrical & Electronics System
Starter
Kick & Electric optional
Chassis & Suspension
Frame Type
Steel, Double cradle frame
Front Suspension
Telehydraulic forks
Rear Suspension
Dual shocks swinging arm fork
Wheels & Brakes
Front Tire Size
3.75-19
Rear Tire Size
4.25-18
Front Brakes
Single 292mm disc
Rear Brakes
Single 203mm drum
Dimension & Weights
Fuel Tank Capacity
2.3 US gallons / 9.0 L
Dry Weight
235 kg / 518 lbs
