Harley Davidson XL 883R Sportster (2004 – 2005)

Harley Davidson XL 883R Sportster (2004 - 2005)

The Harley-Davidson XL 883R Sportster is more than just a motorcycle – it’s an experience that will leave you breathless and craving for more.

With its potent V-Twin engine, the Sportster delivers a rush of power and torque that’s impossible to ignore. Its short wheelbase and responsive handling make it a joy to navigate twisty roads, while its low seat height and upright riding position ensure a comfortable ride for riders of all sizes.

But be warned: this bike is not for the faint of heart. With its 883cc engine producing a healthy 55 horsepower and 54 lb-ft of torque, the Sportster can quickly get out of hand if you’re not careful – just ask anyone who’s ever ridden with Mama Cass behind the handlebars. And yet, that’s part of its charm: it’s a bike that rewards skill and finesse, but also provides plenty of thrills for those willing to push their limits.

And so, if you’re ready to take your riding experience to the next level – or simply want a bike that will put a smile on your face every time you fire up the engine – look no further than the Harley-Davidson XL 883R Sportster.

Key Specifications

Engine TypeFour stroke, 45 V-Twin,Evolution Valve Train Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, two valves per cylinder
Engine Capacity53.8 cubic inches / 883 cc
Max Torque55 ft-lb / 74.6 nm
Fuel Tank Capacity3.3 US gallons / 12.5 L
Weight (Wet/Kerb)588 lbs / 267 kg
Seat Height28.1 inches / 713.7 mm
Harley Davidson XL 883R Sportster (2004 - 2005)

All Specifications

Make & Model

ModelHarley Davidson XL 883R Sportster
Year2004 – 2005

Engine

Engine TypeFour stroke, 45 V-Twin,Evolution Valve Train Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, two valves per cylinder
Displacement53.8 cubic inches / 883 cc
Bore x Stroke76.2 x 96.8 mm
Compression Ratio8.9:1
Max Torque55 ft-lb / 74.6 nm
Engine Management SystemElectronic Sequential Port Fuel Injection (ESPFI)
Lubrication SystemDry sump
Cooling SystemAir cooled

Performance

Top Speedn/a

Transmission

Gearbox5 Speed
Gear Ratios1st 10.782 10.782 10.7822nd 7.702 7.702 7.7025.728 5.728 5.7284th 3rd 4.748 4.748 4.7485th .071 4.071 4.071
Final DriveBelt

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeMild steel tubular frame; circular sections; cast junctions Swingarm Mild steel, rectangular tube sections, stamped junctions; MIG welded
Front Suspension39mm Telescopic forks
Rear SuspensionCoil-over; preload dual-adjustable
Rake29
Trail117 mm / 4.6 in

Wheels & Brakes

Front Tire Size100/90-19 57H
Rear Tire Size150/80B16 71H
Front BrakesSingle 292mm discs 2 piston calipers
Rear BrakesSingle 292mm disc 1 piston calipers

Dimension & Weights

Seat Height28.1 inches / 713.7 mm
Wheelbase60.0 inches / 1524 mm
Ground Clearance141 mm / 5.6 in
Fuel Tank Capacity3.3 US gallons / 12.5 L
Wet (kerb/curb) Weight588 lbs / 267 kg
Dry Weight258.0 kg / 568 lbs

Features

  • Longest continuously produced motorcycle in the Harley-Davidson lineup
  • Over 50 years of production
  • Available with electronically fuel-injected engine
  • H-D’s Electronic Sequential Port Fuel Injection (ESPFI) as standard equipment
  • Oxygen feedback acts independently on each cylinder
  • System “learns” and adjusts to changing conditions
  • Available in Sportster model
  • 883cc displacement available
  • Chopped-out front end available as an option
  • Custom bars available as an option
  • Kick starter available
  • V-Twin engine configuration
  • Four-stroke, air-cooled design
