Harley Davidson XL 883NIron (2013)

The Harley-Davidson Iron 883 is a rebellious take on the iconic Sportster, born from the gritty dirt tracks and drag strips of the 1950s. This V-Twin-powered beast embodies the raw, unbridled essence of motorcycling.

With its dark custom styling, this bike shuns chrome and polish for a rugged, back-alley aesthetic. The straight-cut exhaust and slammed handlebar evoke a bygone era of motorcycle culture, where tearing up asphalt was more important than polishing paint.

The Iron 883’s low MSRP makes it an attractive entry point for those looking to experience the Dark Custom lifestyle. With its Evolution V-Twin powertrain, Electronic Sequential Port Fuel Injection, and rubber-mounted powertrain, this bike delivers a thrilling ride that’s as much about attitude as it is about performance.

And with its very aggressive price point, the Harley-Davidson Iron 883 offers an authentic, throwback riding experience without breaking the bank. The perfect gateway to the world of Dark Custom motorcycles, this bike promises to deliver unbridled excitement and a rebellious spirit that’s hard to find elsewhere.

Key Specifications

Engine Type	Four stroke, 45 V-Twin, OHV, 2 valves per cylinder.
Engine Capacity	883 cc / 50.8cu in/
Max Torque	73 Nm / 7.44 kgf-m / 53.8 ft/lb @ 3750 rpm
Fuel Tank Capacity	3.3 US gallons / 12.5 L
Weight (Wet/Kerb)	565 lbs / 256.3 kg
Seat Height	25.7 inches / 653 mm

*n/a – information not provided by manufacturer

All Specifications

Make & Model

Model	Harley Davidson XL 883NIron
Year	2013

Engine

Engine Type	Four stroke, 45 V-Twin, OHV, 2 valves per cylinder.
Displacement	883 cc / 50.8cu in/
Bore x Stroke	76.2 x 96.8 mm
Compression Ratio	8.8:1
Max Torque	73 Nm / 7.44 kgf-m / 53.8 ft/lb @ 3750 rpm
Cooling System	Air cooled
Exhaust	Chrome, staggered, shorty exhaust with dual mufflers

Performance

Top Speed

n/a

*n/a – information not provided by manufacturer

Transmission

Clutch	Multi-plate clutch with diaphragm spring in oil bath
Gearbox	5 Speed
Gear Ratios	1st 10.407 / 2nd 7.436 / 3rd 5.53 / 4th 4.583 / 5th 3.93
Final Drive	Belt

Electrical & Electronics System

Starter

Electric

Chassis & Suspension

Frame Type	Mild steel, tubular frame, circular sections, cast junctionsSwingarm Mild steel, rectangular tube sections, stamped junctions, MIG welded
Front Suspension	∅39mm Fork
Front Suspension Travel	3.62 inches / 92 mm
Rear Suspension	Coil-over, dual-adjustable preload
Rear Suspension Travel	1.6 inches / 41 mm
Rake	31.1
Trail	117 mm / 4.6 in

Wheels & Brakes

Front Wheel/Rim Size	Black, 13-spoke cast aluminium
Front Tire Size	100/90B19 57H
Rear Wheel/Rim Size	Black, 13-spoke cast auminium
Rear Tire Size	130/90-16
Front Brakes	Single ∅300mm disc, 2 x ∅38mm piston calipers
Rear Brakes	Single ∅260mm disc, 2 x ∅38mm piston calipers

Dimension & Weights

Seat Height	25.7 inches / 653 mm
Wheelbase	59.5 inches / 1519 mm
Ground Clearance	120 mm / 4.7 in
Fuel Tank Capacity	3.3 US gallons / 12.5 L
Wet (kerb/curb) Weight	565 lbs / 256.3 kg

Features

Evolution V-Twin powertrain with Electronic Sequential Port Fuel Injection (ESPFI)
Rubber-mounted powertrain to reduce vibration
5-speed transmission
Dual staggered exhaust
Handlebar-mounted electronic speedometer
Disc brakes
Mid-mounted foot controls
Optional Harley-Davidson Smart Security System with hands-free security fob
Black side covers to match bodywork finish
Michelin Scorcher 31 front and rear tires
Black powder-coated engine and covers
Chrome exhaust with dual straight-cut mufflers
Low front and rear suspension
Classic 3.3-gallon fuel tank
Black, 13-spoke cast aluminum wheels
Chopped rear fender with black supports
Black belt guard
Black fork sliders and black fork gaiters
