The Harley-Davidson XL 1200X Forty-Eight is a raw and unbridled riding experience that embodies the spirit of a classic custom motorcycle.

With its rugged, bulldog-like stance and low profile, this new Sportster model exudes an air of rebelliousness and freedom. The Evolution 1200cc V-Twin engine, with its blacked-out and polished rubber-mounted components, unleashes a torrent of power and performance that’s simply intoxicating.

Riding the Forty-Eight is like getting behind the wheel of a hot rod, with the wind rushing past you and the rumble of the V-Twin engine echoing through your veins. Its low solo seat, under-bar mounted mirrors, and fat balloon tires all contribute to its chiseled customization and aggressive stance.

At Harley-Davidson, they say that the Forty-Eight is “ready to ride as a radical custom and also primed to take on its rider’s character and personality.” We can attest to this – the Forty-Eight is an extension of you, your style, and your rebellious spirit.

Key Specifications

Engine TypeFour stroke, 45 V-Twin, OHV, 2 valves per cylinder.
Engine Capacity1199 cc / 73.2 cu in.
Max Torque107 Nm / 10.9 kgf-m / 79 ft/lbs./ @ 3500 rpm
Fuel Tank Capacity13.7 L / 3.6 US gal
Weight (Wet/Kerb)567 lbs / 257.2 kg
Seat Height26.0 inches / 660 mm
Harley Davidson XL 1200X Forty-Eight (2010)

All Specifications

Make & Model

ModelHarley Davidson XL 1200X Forty-Eight
Year2010

Engine

Engine TypeFour stroke, 45 V-Twin, OHV, 2 valves per cylinder.
Displacement1199 cc / 73.2 cu in.
Bore x Stroke88.8 x 96.8 mm
Compression Ratio9.7:1
Max Torque107 Nm / 10.9 kgf-m / 79 ft/lbs./ @ 3500 rpm
Engine Management SystemElectronic Sequential Port Fuel Injection (ESPFI)
Cooling SystemAir cooled
ExhaustChrome, staggered shorty exhaust with dual slash-cut mufflers

Performance

Top Speedn/a

Transmission

Gearbox5 Speed
Gear Ratios1st 9.315 / 2nd 6.653 / 3rd 4.948 / 4th 4.102 / 5th 3.517:1
Final DriveBelt

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeMild steel, tubular frame; circular sections; cast junctionsSwingarm Mild steel, rectangular tube sections, stamped junctions; MIG welded
Front Suspension∅39mm Fork
Front Suspension Travel5.7 inches / 114 mm
Rear SuspensionCoil-over; preload dual-adjustable
Rake30
Trail107 mm / 4.2 in

Wheels & Brakes

Front Wheel/Rim SizeBlack, laced steel spokes
Front Tire SizeMT90B16
Rear Wheel/Rim SizeBlack, laced steel spokes
Rear Tire Size150/80-B16
Front BrakesSingle ∅300mm disc, 2 x ∅38mm piston calipers
Rear BrakesSingle ∅300mm disc, 2 x ∅38mm piston calipers

Dimension & Weights

Seat Height26.0 inches / 660 mm
Wheelbase1520 / 59.8 in
Ground Clearance100 mm / 3.9 in
Fuel Tank Capacity13.7 L / 3.6 US gal
Wet (kerb/curb) Weight567 lbs / 257.2 kg

Features

  • Blacked and polished rubber-mounted Evolution 1200 cc V-Twin engine
  • Classic 2.1-gallon “peanut” fuel tank
  • Low solo seat
  • Under-bar mounted mirrors
  • Clean rear fender
  • Fat balloon tires
  • Evolution 1200 cc V-Twin engine
  • Electronic Sequential Port Fuel Injection (ESPFI)
  • Broad torque curve
  • Smooth clutch effort
  • Chrome, staggered shorty dual muffler
  • Distinctive Harley-Davidson American V-Twin sound
  • Forward foot controls
  • Low profile custom handlebar
  • Fork-mounted turn signals
  • Slammed speedometer mounting bracket
  • Lightened fork brace
  • Dual texture solo seat for lone rider
