Harley Davidson XL 1200T Superlow (2016)

Harley Davidson XL 1200T Superlow (2016)

Imagine a motorcycle so capable, it can transform even the most mundane trip into an epic adventure.

The Harley-Davidson XL 1200T Superlow is built for freedom, with its lightweight frame and nimble handling allowing riders to carve through city streets and twisty highways with ease. Its low center of gravity, combined with an all-new suspension system, ensures a smooth ride that’s equally at home in tight urban environments as it is on the open road.

But what truly sets this bike apart is its premium styling, from the throaty rumble of its 1200cc V-Twin engine to the flawless chrome and precision paintwork. Every detail has been carefully considered, every element meticulously crafted to create a motorcycle that’s at once stylish and capable.

With its generous 4.5-gallon teardrop fuel tank, lockable saddlebags, and docking points for luggage racks and sissybars, the Superlow is ready for anything you can throw at it – and then some. Fire up the engine, feel the rumble beneath you, and see where this incredible motorcycle takes you.

Key Specifications

Engine TypeFour stroke, 45 V-Twin, OHV, 2 valves per cylinder.
Engine Capacity1202 cc / 73.4 cub in.
Max Torque96 Nm / 9.8 kgf-m / 70.8 ft/lbs @ 3750 rpm
Fuel Tank Capacity17 Litres / US 4.5 gal
Weight (Wet/Kerb)274 kg / 604 lb.s
Seat Height26.1 inches / 663.7 mm
Harley Davidson XL 1200T Superlow (2016)

All Specifications

Make & Model

ModelHarley Davidson XL 1200T Superlow
Year2016

Engine

Engine TypeFour stroke, 45 V-Twin, OHV, 2 valves per cylinder.
Displacement1202 cc / 73.4 cub in.
Bore x Stroke88.9 x 96.8 mm
Compression Ratio10.0:1
Max Torque96 Nm / 9.8 kgf-m / 70.8 ft/lbs @ 3750 rpm
Engine Management SystemElectronic Sequential Port Fuel Injection (ESPFI)
Cooling SystemAir cooled
ExhaustClosed loop exhaust system

Performance

Top Speedn/a

Transmission

Gearbox5 Speed
Gear Ratios1st 9.004 / 2nd 6.432 / 3rd 4.783 / 4th 3.965 / 5th 3.400:1
Final DriveBelt

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeMild steel, tubular frame; circular sections; cast junctionsSwingarm Mild steel, rectangular tube section, stamped junctions; MIG welded
Front Suspension39 mm Forks
Rear SuspensionCoil-over, dual-adjustable preload
Rake31.1
Trail145 mm / 5.7 in

Wheels & Brakes

Front Wheel/Rim SizeBlack/Silver, split 5-spoke castaluminum
Front Tire Size120/70 ZR-18 59W
Rear Wheel/Rim SizeBlack/Silver, split 5-spoke castaluminum
Rear Tire Size150/70 ZR-17 69W
Front BrakesSingle 292 mm disc, 2 piston caliper
Rear BrakesSingle 292mm disc, 1 piston caliper

Dimension & Weights

Seat Height26.1 inches / 663.7 mm
Wheelbase1500 / 59.0 in
Ground Clearance95mm / 3.7 in
Fuel Tank Capacity17 Litres / US 4.5 gal
Wet (kerb/curb) Weight274 kg / 604 lb.s
Dry Weight263 kg / 580 lb.s

Features

  • Light, nimble frame for easy handling
  • Detachable windshield
  • Lockable saddlebags
  • New seat for all-day comfort
  • Low center of gravity
  • All-new suspension
  • 1200cc V-Twin engine
  • Premium paint and flawless chrome
  • Peardrop fuel tank with 4.5 gallons capacity
  • Classic lines on the fuel tank
  • True Custom Finish with chrome accents
  • Chrome air cleaner cover with “1200 Sportster” emblazoned on it
  • Chrome headlamp visor, speedo, and rear turn signal bar
  • Black and chrome timer cover
  • Lockable saddlebags with docking points for sissybar and luggage rack
  • Quick release windshield
  • Split 5-Spoke Cast Aluminum Wheels painted black and machine polished
  • Evolution engine heritage
