The 2020 Harley-Davidson XL 1200R Sportster Roadster is an adrenaline-fueled machine that’s been designed to devour the streets. Its potent 1200cc V-Twin engine delivers massive low-end torque and a soul-satisfying sound, making it a joy to ride.
At its core, this bike is all about raw power and unbridled style. The chopped rear fender and mid-mount controls create an aggressive riding position, while the lightweight aluminium heads and cylinders improve air-cooling efficiency for optimal performance.
But what truly sets the Roadster apart is its exceptional handling and braking capabilities. The 43mm front suspension with inverted forks features cartridge damping, while dual disc front brakes with floating rotors provide confident stopping power. With a low profile, two-up seat and slammed handlebars, you’ll be perfectly positioned for maximum performance.
The Sportster has been a legendary machine since its introduction in 1957, with a storied history of drag racing, flat track racing, land speed records, and countless other adventures. Now, the XL 1200R Sportster Roadster is ready to take on whatever you throw at it – and look incredible doing it.
Key Specifications
Engine Type
Four stroke, 45 V-Twin, OHV, 2 valves per cylinder.
Engine Capacity
1202 cc / 73.4 cub in.
Max Torque
103 Nm (76 lb-ft) @ 3,750 rpm
Fuel Tank Capacity
3.3 US gallons / 12.5 L
Weight (Wet/Kerb)
568 lbs / 259 kg
Seat Height
30.9 inches / 785 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Harley Davidson XL 1200R Sportster Roadster
Year
2020
Engine
Engine Type
Four stroke, 45 V-Twin, OHV, 2 valves per cylinder.
Displacement
1202 cc / 73.4 cub in.
Bore x Stroke
88.9 x 96.8 mm
Compression Ratio
10.0:1
Max Torque
103 Nm (76 lb-ft) @ 3,750 rpm
Engine Management System
Electronic Sequential Port Fuel Injection (ESPFI)
Cooling System
Air cooled
Exhaust
Shorty-dual exhaust with chrome tapered mufflers with laser cut black heat shields
*We strive to provide the most comprehensive and accurate specifications possible. However, certain details may not be available if the manufacturer did not disclose them or if the information is no longer publicly accessible. If you find any discrepancy with any data on this site, please feel free to let us know at contact@throttlecraze.com
