Harley Davidson XL 1200R Sportster Roadster (2006)

Harley Davidson XL 1200R Sportster Roadster (2006)

Step into the saddle of a 1200 Roadster and any stretch of pavement becomes an invitation to freedom. The Evolution powertrain, with its high-compression heads and performance cams, is the perfect companion for devouring miles.

The XL frame’s precision handling makes every corner a thrill, while the triple-disc brakes provide confidence-inspiring stopping power. Wide polished bars and a big speedo/tach combo put all the information you need at your fingertips.

From the chrome headlight visor to the staggered dual pipes, this Roadster is dressed for performance. And with 70 horsepower and 79 ft-lbs of torque from its high-performance XL Evolution engine, you’ll be ready to tackle any road that comes your way. The result: an unforgettable riding experience, every time you fire up the engine.

Key Specifications

Engine TypeFur stroke, 45 V-TwinEvolution Valve Train Pushrod-operated, OHV, 2 valves per cylinder
Engine Capacity73.2 cubic inches / 1199 cc
Max Torque79 ft-lb / 107.3 nm
Fuel Tank Capacity3.3 US gallons / 12.5 L
Weight (Wet/Kerb)585 lbs / 265 kg
Seat Height28.1 inches / 713.7 mm
Harley Davidson XL 1200R Sportster Roadster (2006)

All Specifications

Make & Model

ModelHarley Davidson XL 1200R Sportster Roadster
Year2006

Engine

Engine TypeFur stroke, 45 V-TwinEvolution Valve Train Pushrod-operated, OHV, 2 valves per cylinder
Displacement73.2 cubic inches / 1199 cc
Bore x Stroke88.8 x 96.8 mm
Compression Ratio9.7:1
Max Torque79 ft-lb / 107.3 nm
Engine Management SystemElectronic Sequential Port Fuel Injection (ESPFI)
Lubrication SystemDry-sump
Cooling SystemAir cooled

Performance

Top Speedn/a

Transmission

ClutchWet 9-plate
Gearbox5 Speed
Gear Ratios1st 9.315 9.004 9.0042nd 6.653 6.432 6.4323rd 4.948 4.783 4.7834th 4.102 3.965 3.9655th 3.517 3.400 3.400
Final DriveBelt

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeMild steel, tubular frame, circular sections, cast junctions Swingarm Mild steel rectangular tube sections, stamped junctions, MIG welded
Front Suspension39mm Forks
Rear SuspensionCoil-over, dual-adjustable preload
Rake29.6
Trail117 mm / 4.6 in

Wheels & Brakes

Front Tire Size100/90-19 57H
Rear Tire Size150/80B16 71H
Front BrakesSingle 292mm disc 2 piston calipers
Rear BrakesSingle 292mm disc 1 piston calipers

Dimension & Weights

Seat Height28.1 inches / 713.7 mm
Wheelbase60.0 inches / 1524.0 mm
Ground Clearance141 mm / 5.6 in
Fuel Tank Capacity3.3 US gallons / 12.5 L
Wet (kerb/curb) Weight585 lbs / 265 kg
Dry Weight256 kg /565 lbs

Features

  • Triple-disc brakes
  • Dual front disc brakes
  • High-mount tachometer
  • Rubber-mounted XL Evolution 1200 engine
  • Black powder-coated engine and wrinkle-black covers
  • Smoother, quieter transmission
  • Lighter clutch effort
  • New sidestand design
  • High-compression, high-flow cylinder heads
  • High-performance cams
  • 13-spoke cast aluminum wheels (standard)
  • Laced steel wheels (optional)
  • Wide polished handlebars
  • Classic 3.3-gallon fuel tank
  • Two-up seat
  • Chrome headlight visor
  • Staggered dual pipes
