Harley Davidson XL 1200N Nightster (2009 – 2010)

Harley Davidson XL 1200N Nightster (2009 - 2010)

The Harley-Davidson XL 1200N Nightster is a dark horse in the world of motorcycles, its rat-rod styling and black finishes exuding an air of rebelliousness that’s hard to resist.

Its 1200 Evolution engine is the soulful heart of this machine, growling through a Chrome Slash-Cut Staggered exhaust as it devours the road. The low suspension puts the rider in a more aggressive, leaned-in position, while the new smaller front and rear fenders showcase the bike’s black laced steel wheels.

With its medium gray powder-coated engine and polished covers, this bike is an exercise in contrasts – raw power meets refined sophistication. And when you throw in the optional Smart Security System, you’ll know your Nightster has got your back.

This is no mere clone of a classic; it’s a bold, unapologetic statement of intent from Harley-Davidson – an iron fist in a soft-bellied world.

Key Specifications

Engine TypeFur stroke, 45 V-TwinEvolution Valve Train Pushrod-operated, OHV, 2 valves per cylinder
Engine Capacity73.2 cubic inches / 1199 cc
Max Torque79 ft-lb / 107.3 nm
Fuel Tank Capacity3.3 US gallons / 12.5 L
Weight (Wet/Kerb)665 lbs / 301 kg
Seat Height25.7 inches / 653 mm
Harley Davidson XL 1200N Nightster (2009 - 2010)

All Specifications

Make & Model

ModelHarley Davidson XL 1200N Nightster
Year2009 – 2010

Engine

Engine TypeFur stroke, 45 V-TwinEvolution Valve Train Pushrod-operated, OHV, 2 valves per cylinder
Displacement73.2 cubic inches / 1199 cc
Bore x Stroke88.8 x 96.8 mm
Compression Ratio9.7:1
Max Torque79 ft-lb / 107.3 nm
Engine Management SystemElectronic Sequential Port Fuel Injection (ESPFI)
Lubrication SystemDry-sump
Cooling SystemAir cooled

Performance

Top Speedn/a

Transmission

ClutchWet 9-plate
Gearbox5 Speed
Gear Ratios1st 9.3152nd 6.6533rd 4.9484th 4.1025th 3.517
Final DriveBelt

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeMild steel, tubular frame, circular sections, cast junctions Swingarm Mild steel rectangular tube sections, stamped junctions, MIG welded
Front Suspension39mm Forks
Rear SuspensionCoil-over, dual-adjustable preload
Rake30.5
Trail117 mm / 4.8 in

Wheels & Brakes

Front Tire Size100/90B19 57H
Rear Tire Size150/80B16 77H
Front BrakesSingle 292mm disc 2 piston calipers
Rear BrakesSingle 292mm disc 1 piston caliper

Dimension & Weights

Seat Height25.7 inches / 653 mm
Wheelbase59.8 inches / 1519 mm
Ground Clearance100 mm / 4.7 in
Fuel Tank Capacity3.3 US gallons / 12.5 L
Wet (kerb/curb) Weight665 lbs / 301 kg
Dry Weight252 kg / 335 lbs

Features

  • 1200 Evolution engine with 73 cubic-inch displacement
  • Rubber-mounted XL Evolution 1000cc/1200cc engine options
  • Chrome Slash-Cut Staggered exhaust
  • Medium Gray powder-coated engine with polished covers
  • Black laced steel wheels, 19-inch front / 16-inch rear
  • New low profile front fender
  • Black low-rise handlebar
  • Sportster Classic solo seat
  • Chrome Slash Cut Staggered Shorty Dual exhaust
  • Black mid-mount foot controls
  • Lowest-Profile rear shocks
  • Lowest-Profile front forks
  • Classic 3.3-gallon fuel tank
  • Black front forks with gaiters
  • Bullet hole belt guard and front fender supports
  • Side-mount license plate holder
  • Combination rear brake/tail/turn lights
  • Lowered front and rear suspension
