Harley Davidson XG 750 Street (2020)

Harley Davidson XG 750 Street (2020)

The Harley-Davidson XG 750 Street is a sleek and nimble urban warrior, engineered to devour city streets with its authentic attitude.

Its liquid-cooled Revolution X powertrain delivers a smooth, progressive throttle response that’s perfect for navigating congested traffic. The sophisticated ABS system provides confidence-inspiring control, while the low weight and center of gravity make it effortless to lift off the side stand or pull out from the curb.

The bike’s compact dimensions and low seat height (just 28 inches) make it an ideal choice for urban riders, with a narrow frame and seat allowing for easy reach. The specifically tuned geometry provides a smooth ride and excellent handling over rough pavement, while the all-black two-into-one exhaust system adds to its aggressive stance.

With its blacked-out front end, caf-inspired speed screen, and chrome medallion on the fuel tank, this bike is ready to conquer the urban jungle with style. The Harley-Davidson XG 750 Street is a thrilling ride that’s perfect for anyone who wants to carve through city streets with confidence and flair.

Key Specifications

Engine TypeFour stroke, Revolution X 60 V-Twin, SOHC, 4 valves per cylinder.
Engine Capacity749 cc / 46 cub in.
Max Torque59 Nm / 6.0 kgf-m / 43.5 ft/lb @ 4000 rpm
Fuel Tank Capacity3.5 US gallons / 13.1 L
Weight (Wet/Kerb)514 lbs / 233 kg
Seat Height25.7 inches / 720 mm
Harley Davidson XG 750 Street (2020)

All Specifications

Make & Model

ModelHarley Davidson XG 750 Street
Year2020

Engine

Engine TypeFour stroke, Revolution X 60 V-Twin, SOHC, 4 valves per cylinder.
Displacement749 cc / 46 cub in.
Bore x Stroke85 x 66 mm
Compression Ratio11.0:1
Max Torque59 Nm / 6.0 kgf-m / 43.5 ft/lb @ 4000 rpm
Engine Management SystemMikuni Single Port Fuel Injection, 38 mm bore
Cooling SystemLiquid cooled

Performance

Top Speedn/a

Transmission

ClutchMulti-plate with diaphragm spring in oil bath
Gearbox6 Speed
Gear Ratios1st 14.25 / 2nd 10.07 / 3rd 7.45 / 4th 5.99 / 5th 5.04 / 6th 4.53:1
Final DriveBelt

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeMild tubular steel w/ rectangular backbone
Front SuspensionNon-adjustable 37mm forks
Front Suspension Travel140 mm / / 5.5 in
Rear SuspensionSpring-preload adjustable dual shocks
Rear Suspension Travel3.5 inches / 94 mm
Rake32
Trail110 mm / 4.5 in.

Wheels & Brakes

Front Wheel/Rim SizeBlack, 7-Spoke Cast Aluminum with Machined Rim Highlights
Front Tire Size100/80 R17
Rear Wheel/Rim SizeBlack, 7-Spoke Cast Aluminum with Machined Rim Highlights
Rear Tire Size140/75 R15
Front BrakesSingle disc, 2 piston caliper
Rear BrakesSingle disc, 2 piston caliper

Dimension & Weights

Seat Height25.7 inches / 720 mm
Wheelbase60.4 inches / 1534 mm
Ground Clearance145 mm / 5.7 in.
Fuel Tank Capacity3.5 US gallons / 13.1 L
Wet (kerb/curb) Weight514 lbs / 233 kg
Dry Weight223 kg / 492 lbs

Features

  • Liquid-cooled Revolution X powertrain
  • Low seat height (28-inches)
  • Broad handlebar sweep for confidence and maneuverability
  • Caf-style speed screen
  • Black front fork gaiters
  • All-black exhaust system
  • Aggressive slash on the tail section
  • Smart Security System
  • Optional two-tone paint schemes
  • ABS (factory-installed)
  • Low weight
  • Low center of gravity
  • Narrow frame and seat for easier reach
  • Geometry of frame specifically tuned for bike’s weight
  • Chrome medallion made of steel on fuel tank
