Harley Davidson VRSCX Screamin’ Eagle/Vance & Hines NHRA Pro Stock L.E. (2007)

Harley Davidson VRSCX Screamin' Eagle/Vance & Hines NHRA Pro Stock L.E. (2007)

The Harley-Davidson VRSCX Screamin’ Eagle/Vance & Hines NHRA Pro Stock L.E. is a powerhouse of a motorcycle, boasting an incredible 123 horsepower and 86 ft. lbs. of torque from its 1250cc Revolution V-Twin engine.

This beast of a bike is not just about raw power; it’s also designed to deliver a thrilling riding experience with its radical styling and aggressive stance. From the smoked drag visor windshield to the 240mm wide rear tire, every detail has been carefully crafted to evoke the spirit of competition.

Whether you’re a seasoned rider or just looking for an adrenaline rush, the VRSCX is sure to put a smile on your face. Its liquid-cooled engine and advanced features like ESPFI and Brembo brakes make it a true performer on the road and at the drag strip. With only 1,400 units produced, this limited-edition bike is a rare opportunity for enthusiasts to own a piece of Harley-Davidson’s rich drag racing heritage.

Key Specifications

Engine TypeFour stroke, 60 V-twin, DOHC, 4 valve per cylinder.
Engine Capacity76.2 cubic inches / 1250 cc
Max Power123 hp / 90.5 kW @ 8000 rpm
Max Torque115 Nm / 86 ft-lbs@ 7000 rpm
Fuel Tank Capacity5.0 US gallons / 18.9 L
Weight (Wet/Kerb)670 lbs / 304 kg
Seat Height26 inches / 660.40 mm
Harley Davidson VRSCX Screamin' Eagle/Vance & Hines NHRA Pro Stock L.E. (2007)

All Specifications

Make & Model

ModelHarley Davidson VRSCX Screamin’ Eagle/Vance & Hines NHRA Pro Stock L.E.
Year2007

Engine

Engine TypeFour stroke, 60 V-twin, DOHC, 4 valve per cylinder.
Displacement76.2 cubic inches / 1250 cc
Bore x Stroke105 x 72 mm
Compression Ratio11.3;1
Max Horsepower123 hp / 90.5 kW @ 8000 rpm
Max Torque115 Nm / 86 ft-lbs@ 7000 rpm
Engine Management SystemElectronic Sequential Port Fuel Injection
Lubrication SystemGerotor, wet sump
Cooling SystemLiquid cooled

Performance

Top Speedn/a

Transmission

ClutchNine plate wet pressure fed with integral compensation
Gearbox5 Speed
Gear Ratios1st 11.752 10.969 10.9692nd 7.898 7.371 7.3713rd 6.322 5.900 5.9004th 5.459 5.095 5.0955th 4.889 4.563 4.563
Final DriveBelt

Electrical & Electronics System

BatterySealed,maintenance-free, 12-volt, 12 amp-hour, 200 cca (per Battery Council International rating)
StarterElectric

Chassis & Suspension

Frame TypeSteel perimeter upper frame w/hydroformed main rails and bolt-on lower frame rails, MIG welded
Front SuspensionHuge 49mm telescopic forks
Front Suspension Travel3.9 inches / 100 mm
Rear SuspensionDual coil over adjustable shock
Rear Suspension Travel2.7 inches / 70 mm
Rake34
Trail114 mm / 4.5 in

Wheels & Brakes

Front Tire SizeD207F 120/70ZR-19 60W
Rear Tire SizeD207F 240/40R18 74W
Front Brakes2x 300mm discs 4 piston calipers
Rear BrakesSingle 300mm disc 4 piston caliper

Dimension & Weights

Seat Height26 inches / 660.40 mm
Wheelbase66.9 inches / 1699 mm
Fuel Tank Capacity5.0 US gallons / 18.9 L
Wet (kerb/curb) Weight670 lbs / 304 kg
Dry Weight289 kg / 637 lbs

Features

  • 1250cc Revolution V-Twin engine
  • 123 horsepower at 8000 rpm
  • 86 ft. lbs. torque at 7000 rpm
  • Liquid-cooled engine
  • NHRA Screamin’ Eagle/Vance & Hines NHRA Pro Stock Bike paint scheme
  • Smoked drag visor windshield
  • 240mm wide rear tire
  • Five-gallon under-seat fuel cell
  • 36-degree fork angle
  • 49mm custom forks
  • Brembo triple-disc brakes
  • Hydroformed frame
  • Brushed, Profile Laced Aluminum 19-inch front wheel
  • Machined, Slotted Disc Cast Aluminum 18-inch rear wheel
  • High performance carbon fiber final drive belt
  • Electronic Sequential Port Fuel Injection (ESPFI)
  • Low 26-inch drag-style seat
  • Forward controls with shorter drag-style handlebar
