Harley Davidson VRSCDX Night Rod Special (2012)

Harley Davidson VRSCDX Night Rod Special (2012)

The Harley-Davidson VRSCDX Night Rod Special is a dark horse in the world of motorcycles. Its 60-degree V-twin engine roars to life with a four-stroke punch, delivering a raw, unbridled power that’s impossible to ignore.

This is a bike that defies convention, its sleek, blacked-out design and aggressive stance commanding attention wherever it goes. The restyled Night Rod Special features improved ergonomics, reduced reach to both the rider footpegs and handlebar, and an enhanced riding position that invites you to push the limits.

Inverted front forks and retuned rear suspension work in harmony with the powerful 1250cc Revolution engine to deliver a ride that’s as responsive as it is exhilarating. With its Assist and Slip clutch, five-speed transmission, and high-performance carbon-fiber drive belt, this bike is built for speed and agility. The result is an unforgettable riding experience that will leave you breathless.

Key Specifications

Engine TypeFour stroke, 60 V-twin, DOHC, 4 valve per cylinder.
Engine Capacity1247 cc / 76.1 cu in
Max Power123 hp / 90.5 kW @ 8000 rpm
Max Torque116 Nm / 86 ft. lbs@ 7250 rpm
Fuel Tank Capacity5.0 US gallons / 18.9 L
Weight (Wet/Kerb)670 lbs / 304.0 kg
Seat Height25.6 inches / 650 mm
Harley Davidson VRSCDX Night Rod Special (2012)

All Specifications

Make & Model

ModelHarley Davidson VRSCDX Night Rod Special
Year2012

Engine

Engine TypeFour stroke, 60 V-twin, DOHC, 4 valve per cylinder.
Displacement1247 cc / 76.1 cu in
Bore x Stroke105 x 72 mm
Compression Ratio11.5;1
Max Horsepower123 hp / 90.5 kW @ 8000 rpm
Max Torque116 Nm / 86 ft. lbs@ 7250 rpm
Engine Management SystemElectronic Sequential Port Fuel Injection
Cooling SystemLiquid cooled
ExhaustStraight-shot exhaust with brushed finish dual mufflers; black end caps and exhaust shield

Performance

Top Speedn/a

Transmission

Gearbox5 Speed
Gear Ratios1st 11.752 10.969 10.969 /2nd 7.898 7.371 7.371 / 3rd 6.322 5.900 5.900 4th 5.459 5.095 5.095 / 5th 4.889 4.563 4.563
Final DriveBelt

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeSteel perimeter upper frame w/hydroformed main rails and bolt-on lower frame rails, MIG welded
Front SuspensionHuge 49mm telescopic forks
Front Suspension Travel3.9 inches / 100 mm
Rear SuspensionDual coil over adjustable shock
Rear Suspension Travel2.7 inches / 70 mm
Trail142 mm / 5.6 in

Wheels & Brakes

WheelsOptional Style Type Black, Split 5-Spoke Cast Aluminum w/ Machined Pinstripe Standard on Select Colors
Front Wheel/Rim SizeBlack, Split 5-Spoke Cast Aluminum w/ Orange Pinstripe
Front Tire Size120/70ZR-19 60W
Rear Wheel/Rim SizeBlack, Split 5-Spoke Cast Aluminum w/ Orange Pinstripe
Rear Tire Size240/40R-18 79V
Front Brakes2x 300mm discs 4 piston calipers
Rear BrakesSingle 300mm disc 4 piston caliper

Dimension & Weights

Seat Height25.6 inches / 650 mm
Wheelbase67 inches / 1705 mm
Ground Clearance114 mm / 4.5 in
Fuel Tank Capacity5.0 US gallons / 18.9 L
Wet (kerb/curb) Weight670 lbs / 304.0 kg

Features

  • 1250cc liquid-cooled V-Twin engine
  • Dual overhead camshafts
  • Four-valve cylinder heads
  • Electronic Sequential Port Fuel Injection (ESPFI)
  • Assist and Slip clutch
  • Five-speed transmission
  • High-performance carbon-fiber drive belt
  • Michelin Scorcher radial tires
  • 240mm rear tire
  • Brembo triple-disc performance brakes
  • Optional factory-installed anti-lock braking system (ABS)
  • Smart Security System with proximity-based, hands-free security fob
  • Black Split 5-Spoke Cast Aluminum wheels
  • Tapered tail section with flush-mount LED taillight
  • Pullback handlebar
  • Reduced reach, forward-mounted rider footpegs
  • Inverted front forks
  • Two-up seat with custom stitching
  • Stylized black speed screen visor
