Harley Davidson Sport Glide (2018 - 2019)

The Harley-Davidson Sport Glide is a bike that defies categorization, blending the best of both worlds to create an unparalleled riding experience.

With its all-new Softail frame, this motorcycle boasts a lightweight and nimble feel that’s unlike any other Harley-Davidson Custom or Touring model. Inverted front forks and a fully adjustable monoshock rear suspension let you fine-tune your ride for optimal performance and comfort.

The rigid-mounted Milwaukee-Eight 107 engine is the beating heart of this beast, delivering a thrilling dose of power and torque that’s perfectly suited to both long-distance touring and urban shenanigans. Whether you’re loading up with gear or stripping down for a solo blast through the city streets, the Sport Glide has got your back.

Its aggressive styling is matched only by its versatility, making it the perfect companion for any ride, anywhere, anytime. With detachable locking saddlebags and a quick-detach front mini-fairing, you can switch up your look and feel in an instant. So why settle for just one kind of ride when you can have them all? The Harley-Davidson Sport Glide is ready to take you on the ride of a lifetime – whenever, wherever.

Key Specifications

Engine Type	Four stroke, V-Twin, Milwaukee-Eight 107, pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Engine Capacity	107 cubic inches / 1746 cc
Max Torque	146 Nm / 108 ft-lb @ 2750 rpm
Fuel Tank Capacity	5.0 US gallons / 18.9 L
Weight (Wet/Kerb)	699 lbs / 317 kg
Seat Height	26.8 inches / 680 mm

*n/a – information not provided by manufacturer

Harley Davidson Sport Glide (2018 - 2019)

All Specifications

Make & Model

Model	Harley Davidson Sport Glide
Year	2018 – 2019

Engine

Engine Type	Four stroke, V-Twin, Milwaukee-Eight 107, pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Displacement	107 cubic inches / 1746 cc
Bore x Stroke	100 x 111 mm
Compression Ratio	10.0:1
Max Torque	146 Nm / 108 ft-lb @ 2750 rpm
Engine Management System	Electronic Sequential Port Fuel Injection (ESPFI)
Lubrication System	Pressurized, dry-sump with oil cooler
Cooling System	Air cooled
Exhaust	2-into-1, catalyst in muffler

Performance

Top Speed

n/a

*n/a – information not provided by manufacturer

Transmission

Clutch	Mechanical, 10 plate wet, assist & conventional
Gearbox	6 Speed
Gear Ratios	1st 9.311 / 2nd 6.454 / 3rd 4.793 / 4th 3.882 / 5th 3.307 / 6th 2.79:1
Final Drive	Belt, 32/66 ratio

Electrical & Electronics System

Starter	Electric
ABS	Standard

Chassis & Suspension

Frame Type	Mild steel, tubular frame, rectangular section backbone, stamped, cast, and forged junctions, MIG welded, aluminum forged fender supports
Front Suspension	Single cartridge 43 mm inverted with aluminum fork triple clamps, triple rate spring
Front Suspension Travel	5.1 inches / 130 mm
Rear Suspension	Hidden, free piston, coil-over monoshock, 43mm stroke, toothless hydraulic pre-load adjustment
Rear Suspension Travel	3.4 inches / 86 mm
Rake	30
Trail	150 mm / 5.9 in
Swingarm	Mild steel, tubular sections, stamped x-member, forged axle junctions, MIG welded, removable belt spacer

Wheels & Brakes

Wheels	Black, machine highlighted, Mantis cast aluminum
Front Tire Size	130/70B18 63H BW
Rear Tire Size	180/70B16 77H BW
Front Brakes	Single 300 mm discs, 4 piston fixed caliper
Rear Brakes	Single 292 mm disc, 2 piston floating caliper
ABS	Standard

Dimension & Weights

Overall Length	2325 mm / 91.5 in
Overall Width	960 mm / 37.8 in
Overall Height	1120 mm / 44.1 in
Seat Height	26.8 inches / 680 mm
Wheelbase	64 inches / 1625 mm
Ground Clearance	120 mm / 4.7 in
Fuel Tank Capacity	5.0 US gallons / 18.9 L
Wet (kerb/curb) Weight	699 lbs / 317 kg
Dry Weight	304 kg / 670 lbs

Features

All-new Softail frame
Lightweight, nimble ride
Inverted front forks
Fully adjustable, monoshock rear suspension
Milwaukee-Eight 107 engine
Piles of white-knuckle power
Rigid-mounted counterbalanced engine
Smooth ride
Harley feel retained
Detachable locking saddlebags
Quick tool-free on and off
Front mini-fairing with wind deflectors
Aggressive Mantis black and silver cast wheels
Black mufflers
LED forward-lighting system
Keyless ignition
