Harley Davidson Softail Street Bob (2020)

Harley Davidson Softail Street Bob (2020)

The Harley-Davidson Softail Street Bob is a masterclass in stripped-down, high-octane rebellion.

Its 107-cubic inch Milwaukee-Eight engine unleashes a torrent of power and torque, begging to be unleashed on the open road. The two-fists-in-the-wind riding experience is all about raw emotion and unbridled freedom.

With its blacked-out surfaces, spoked wheels, and hidden digital instrumentation, this bike embodies the essence of custom motorcycling: attitude, style, and a healthy disregard for convention.

Key Specifications

Engine TypeFour stroke, V-Twin, Milwaukee-Eight 107, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Engine Capacity1746 cc / 107 cub in
Max Torque145 Nm / 107 ft-lb @ 3250 rpm
Fuel Tank Capacity3.5 US gallons / 2.0 L
Weight (Wet/Kerb)654.7 lbs / 297 kg
Seat Height26.8 inches / 680 mm
Harley Davidson Softail Street Bob (2020)

All Specifications

Make & Model

ModelHarley Davidson Softail Street Bob
Year2020

Engine

Engine TypeFour stroke, V-Twin, Milwaukee-Eight 107, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Displacement1746 cc / 107 cub in
Bore x Stroke100 x 111 mm
Compression Ratio10.0:1
Max Torque145 Nm / 107 ft-lb @ 3250 rpm
Engine Management SystemElectronic Sequential Port Fuel Injection (ESPFI)
Lubrication SystemPressurized, dry-sump with oil cooler
Cooling SystemAir cooled
Exhaust2-into-1-into-2 dual side, catalyst in muffler

Performance

Top Speedn/a

Transmission

ClutchMulti-plate, wet
Gearbox6 Speed
Gear Ratios1st 9.311 / 2nd 6.454 / 3rd 4.793 / 4th 3.882 / 5th 3.307 / 6th 2.79:1
Final DriveBelt

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Front SuspensionShowa Inverted forks
Rear SuspensionMono Shock
Rake30
Trail157 mm / 6.2 in

Wheels & Brakes

Front Wheel/Rim Size9 Gloss Black, Steel Laced
Front Tire Size100/90B19,57H,BW
Rear Wheel/Rim SizeGloss Black, Steel Laced
Rear Tire Size150/80B16,77H,BW
Front BrakesSingle disc, 4 piston caliper, fixed
Rear BrakesSingle disc, 2 piston caliper, floating

Dimension & Weights

Overall Length2320 mm / 91.3 in
Seat Height26.8 inches / 680 mm
Wheelbase64.2 inches / 1630 mm
Ground Clearance125 mm / 4.9 in
Fuel Tank Capacity3.5 US gallons / 2.0 L
Wet (kerb/curb) Weight654.7 lbs / 297 kg
Dry Weight286 kg / 630.5 lbs

Features

  • 107-cubic inch Milwaukee-Eight engine
  • Forward controls
  • Chopped fenders
  • Hidden digital instrumentation
  • Spoked wheels
  • Mini-ape handlebars
  • Digital instrumentation
  • Keyless ignition
  • USB charging port
  • Signature LED forward lighting
  • Lightweight frame design
  • Responsive new suspension
  • Powerful Big-Twin engine
  • Crisp throttle response
  • Soul-satisfying rumble
  • Racing-style cartridge fork
  • Linear damping characteristics
  • Easily adjustable mono-shock rear suspension
