The Harley-Davidson Softail Standard motorcycle embodies the quintessential cruiser experience, blending raw power with timeless style.

At its core lies the Milwaukee-Eight V-Twin powertrain, delivering unbridled performance and a low rumble that’s impossible to ignore. This potent engine is masterfully crafted to be the focal point of the bike, with polished rocker covers and timer housing adding to its allure.

The Softail Standard’s lean profile, steeped in attitude, is further accentuated by sleek laced wheels, finished in brilliant chrome, and a solo seat that exposes the chopped rear fender. A 3.5-gallon fuel tank reveals the frame and engine, while an all-black Milwaukee-Eight 107 engine creates a striking contrast against the Vivid Black paint.

The result is a motorcycle that exudes classic simplicity, yet packs a punch with its raw power and unrelenting performance, making it the ultimate ride for those who crave the pure essence of Harley-Davidson.

Key Specifications

Engine TypeFour stroke, V-Twin, Milwaukee-Eight 107, pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Engine Capacity107 cubic inches / 1746 cc
Max Torque110 ft-lb / 149 nm
Fuel Tank Capacity3.5 US gallons / 13.2 L
Weight (Wet/Kerb)655 lbs / 297 kg
Seat Height25.8 inches / 655 mm
Harley Davidson Softail Standard (2020)

All Specifications

Make & Model

ModelHarley Davidson Softail Standard
Year2020

Engine

Engine TypeFour stroke, V-Twin, Milwaukee-Eight 107, pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Displacement107 cubic inches / 1746 cc
Bore x Stroke100 x 111 mm
Compression Ratio10.0:1
Max Torque110 ft-lb / 149 nm
Engine Management SystemElectronic Sequential Port Fuel Injection (ESPFI)
Lubrication SystemPressurized, dry-sump with oil cooler
Cooling SystemAir cooled
Exhaust2-into-2 shotgun, catalyst in muffler

Performance

Top Speedn/a

Transmission

ClutchMechanical, 10 plate wet, assist & conventional
Gearbox6 Speed
Gear Ratios1st 9.311 / 2nd 6.454 / 3rd 4.793 / 4th 3.882 / 5th 3.307 / 6th 2.79
Final DriveBelt, 32/66 ratio

Electrical & Electronics System

StarterElectric
ABSOptional

Chassis & Suspension

Frame TypeMild steel, tubular frame, rectangular section backbone, stamped, cast, and forged junctions, MIG welded, aluminum forged fender supports
Front SuspensionDual-bending valve 49 mm telescopic with aluminum fork triple clamps, dual rate spring
Front Suspension Travel5.1 inches / 130 mm
Rear SuspensionHidden, free piston, coil-over monoshock, 43mm stroke, cam-style preload adjustment
Rear Suspension Travel3.4 inches / 86 mm
Rake30
Trail157 mm / 6.2 in
SwingarmMild steel, tubular sections, stamped x-member, forged axle junctions, MIG welded, removable belt spacer

Wheels & Brakes

WheelsChrome Steel Laced
Front Tire Size100/90B19,57H,BW
Rear Tire Size150/80B16,77H,BW
Front BrakesSingle 300mm disc, 4 piston fixed caliper
Rear BrakesSingle 292mm disc, 2 piston floating caliper
ABSOptional

Dimension & Weights

Overall Length2320 mm / 91.3 in
Overall Width865 mm / 34.1 in
Overall Height1160 mm / 45.7 in
Seat Height25.8 inches / 655 mm
Wheelbase64.2 inches / 1630 mm
Ground Clearance125 mm / 4.9 in
Fuel Tank Capacity3.5 US gallons / 13.2 L
Wet (kerb/curb) Weight655 lbs / 297 kg
Dry Weight286 kg / 630 lbs

Features

  • Dual-bending valve 49 mm telescopic fork
  • Aluminum fork triple clamps
  • Hidden, free piston, coil-over monoshock suspension
  • 43mm stroke
  • Cam-style preload adjustment
  • Milwaukee-Eight V-Twin powertrain
  • Vivid Black paint and chrome finishes
  • Solo seat with chopped rear fender
  • 3.5-gallon fuel tank
  • All-black Milwaukee-Eight 107 engine with polished rocker, primary, and timer covers
  • Center-bolt, round air cleaner cover
  • Chrome shields and mufflers for 2-into-2 offset shotgun exhaust
  • Classic laced wheels (19-inch front, 16-inch rear)
  • Clear-coated fork sliders
  • Polished triple-clamps, top clamp, and riser
  • Chromed headlamp bezel and turn signals
  • Mini-ape handlebar
  • Compact electronic instrument with digital display
  • Rigid-mounted powertrain for enhanced chassis stiffness
  • Mono-shock rear suspension with coil-over shock and emulsion technology
