Harley Davidson Softail Low Rider ST (2022)

Harley Davidson Softail Low Rider ST (2022)

The Harley-Davidson Softail Low Rider ST (2022) embodies the perfect blend of power, style, and versatility. At its heart lies a formidable Four Stroke, V-Twin Milwaukee-Eight 117 engine, delivering an incredible 125 ft-lbs of torque at 3500 RPM.

This potent powerplant is matched to a high-performance camshaft, tuned Heavy Breather intake, and offset shotgun exhaust, all working in harmony to produce an exhilarating riding experience. The precision oil/air cooling system ensures optimal performance under various conditions.

Riding the Low Rider ST is akin to feeling the raw energy of the open road. With its sleek design and robust power output, this motorcycle is designed for those who crave unbridged power and effortless handling. Whether navigating twisties or cruising down a highway, the Harley-Davidson Softail Low Rider ST (2022) promises an unforgettable experience that will leave you yearning for more.

Key Specifications

Engine TypeFour stroke, V-Twin, Milwaukee-Eight 117, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Engine Capacity117 cubic inches / 1923 cc
Max Power103 hp / 77 kW @ 4750 rpm
Max Torque125 ft-lb / 169 nm
Fuel Tank Capacity5 US gallons / 18.9 L
Seat Height27 inches / 686 mm
Harley Davidson Softail Low Rider ST (2022)

All Specifications

Make & Model

ModelHarley Davidson Softail Low Rider ST
Year2022

Engine

Engine TypeFour stroke, V-Twin, Milwaukee-Eight 117, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Displacement117 cubic inches / 1923 cc
Bore x Stroke103.5 x 114.3 mm
Compression Ratio10.2:1
Max Horsepower103 hp / 77 kW @ 4750 rpm
Max Torque125 ft-lb / 169 nm
Engine Management SystemElectronic Sequential Port Fuel Injection (ESPFI)
Lubrication SystemPressurized, dry-sump with oil cooler
Cooling SystemAir cooled
Exhaust2-into-2 offset shotgun; catalyst in muffler

Performance

Top Speedn/a

Transmission

ClutchMechanical, 10 plate wet, assist & conventional
Gearbox6 Speed
Gear Ratios1st 9.311 2nd 6.454 3rd 4.793 4th 3.882 5th 3.307 6th 2.79
Final DriveBelt, 32/66 ratio

Electrical & Electronics System

StarterElectric
ABSStandard

Chassis & Suspension

Frame TypeMild steel, tubular frame; rectangular section backbone; stamped, cast, and forged junctions; MIG welded; aluminum forged fender supports
Front SuspensionSingle cartridge 43 mm inverted with aluminum fork triple clamps; triple rate spring
Front Suspension Travel5.1 inches / 130 mm
Rear SuspensionHidden, free piston, coil-over monoshock; 56 mm stroke; hydraulic preload adjustment
Rear Suspension Travel4.4 inches / 112 mm
Rake28
Trail145 mm / 5.7 in
SwingarmMild steel, tubular sections, stamped x-member, forged axle junctions; MIG welded; removable belt spacer

Wheels & Brakes

WheelsDark bronze, Radiate cast aluminum wheel
Front Tire Size110/90B19,62H,BW
Rear Tire Size180/70B16,77H,BW
Front Brakes2 x 300mm discs, 4 piston caliper
Rear BrakesSingle 292mm disc, 2 piston floating caliper
ABSStandard

Dimension & Weights

Seat Height27 inches / 686 mm
Wheelbase63.6 inches / 1615 mm
Ground Clearance150 mm / 5.9 in
Fuel Tank Capacity5 US gallons / 18.9 L
Dry Weight315 kg / 694 lbs

Features

  • Four stroke V-Twin engine
  • Milwaukee-Eight 117 powertrain
  • Pushrod-operated overhead valves
  • Hydraulic self-adjusting lifters
  • Single-fire non-wasted map-controlled spark ignition
  • 6-speed transmission
  • Gear ratios: 1st 9.311, 2nd 6.454, 3rd 4.793, 4th 3.882, 5th 3.307, 6th 2.79
  • Single cartridge fork with 43mm inverted aluminum fork triple clamps
  • Triple rate spring
  • Hidden free piston coil-over monoshock with hydraulic preload adjustment
  • 56mm stroke
  • Length: 2365 mm / 93.1 in
  • Width: 870 mm / 34.3 in
  • Height: 1300 mm / 51.2 in
  • 117 cubic inch displacement
  • 125 ft lbs torque at 3500 RPM
  • High-performance camshaft
  • Heavy Breather intake with forward-facing exposed filter element
  • 2-into-2 offset shotgun exhaust
