Harley Davidson Softail Low Rider (2018 – 2019)

Harley Davidson Softail Low Rider (2018 - 2019)

The Harley-Davidson Softail Low Rider embodies the spirit of individualism that defines the custom chopper era. Its rake on the front end, dual gauges on the tank, and 70s-inspired graphics evoke a nostalgic charm reminiscent of its predecessor.

However, this is not just a retro tribute – it’s a powerful machine designed for speed, agility, and unrelenting torque. The Milwaukee-Eight 107 engine delivers massive power with refined refinement, allowing riders to carve corners with ease.

With modern touches like cast wheels and LED forward lighting, the Low Rider seamlessly blends traditional style with contemporary flair. Its lightweight frame and high-performance suspension enable a riding experience that’s both responsive and exhilarating.

Whether you’re a seasoned rider or just starting out, the Harley-Davidson Softail Low Rider is sure to leave an indelible mark on your senses – it’s a custom chopper look for a new generation.

Key Specifications

Engine TypeFour stroke, V-Twin, Milwaukee-Eight 107, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Engine Capacity1746 cc / 107 cub in
Max Torque145 Nm / 107 ft-lb @ 3250 rpm
Fuel Tank Capacity5 US gallons / 18.9 L
Seat Height27.2 inches / 690 mm
Harley Davidson Softail Low Rider (2018 - 2019)

All Specifications

Make & Model

ModelHarley Davidson Softail Low Rider
Year2018 – 2019

Engine

Engine TypeFour stroke, V-Twin, Milwaukee-Eight 107, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Displacement1746 cc / 107 cub in
Bore x Stroke100 x 111 mm
Compression Ratio10.0:1
Max Torque145 Nm / 107 ft-lb @ 3250 rpm
Engine Management SystemElectronic Sequential Port Fuel Injection (ESPFI)
Lubrication SystemPressurized, dry-sump with oil cooler
Cooling SystemAir cooled
Exhaust2-into-1-into-2 dual side, catalyst in muffler

Performance

Top Speedn/a

Transmission

ClutchMulti-plate, wet
Gearbox6 Speed
Gear Ratios1st 9.311 / 2nd 6.454 / 3rd 4.793 / 4th 3.882 / 5th 3.307 / 6th 2.79
Final DriveBelt

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Front SuspensionShowa Inverted forks
Rear SuspensionMono Shock
Rake30
Trail163 mm / 6.4 in

Wheels & Brakes

Front Wheel/Rim SizeBlack, machine highlighted, Radiate cast aluminium wheel
Front Tire Size110/90B19,62H,BW
Rear Wheel/Rim SizeBlack, machine highlighted, Radiate cast aluminium wheel
Rear Tire Size180/70B16,77H,BW
Front Brakes2 x disc, 4 piston caliper
Rear BrakesSingle disc, 2 piston floating caliper

Dimension & Weights

Seat Height27.2 inches / 690 mm
Wheelbase64.2 inches / 1630 mm
Ground Clearance130 mm / 5.1 in
Fuel Tank Capacity5 US gallons / 18.9 L
Dry Weight287 kg / 633 lbs

Features

  • Milwaukee-Eight 107 engine
  • Lighter and stiffer frame
  • High-performance suspension
  • Dual tank gauges
  • Cast wheels
  • LED forward lighting
  • Keyless ignition
  • Throwback style with 70s-inspired graphics
  • Classic chrome features
  • New seats
  • More lean angle
  • Chrome features
  • Milwaukee-Eight engine
  • All-new Softail frame
  • High-performance front suspension
  • High performance rear mono shock
  • Easily adjustable rear suspension
