The Harley-Davidson Softail Fat Boy Special is a behemoth of a motorcycle that embodies the very essence of American muscle. Its black powder-coated counter-balanced Twin Cam 103BTM engine roars to life with a raw, unbridled power that’s impossible to ignore.
Underneath its fat tires and chunky handlebars, this bike packs a punch that’ll leave you breathless as it devours the road ahead. With an unmistakable profile that’s equal parts vintage charm and modern muscle, the Fat Boy Special is a style icon that defies time itself.
From its gleaming horseshoe oil tank to its sleek, minimalist design, every part of this bike has been crafted with precision and passion – a true testament to Harley-Davidson’s unwavering commitment to authenticity. Whether you’re cruising down the highway or carving through twisty roads, the Fat Boy Special is an unforgettable riding experience that will leave you craving more.
Riding the Softail Fat Boy Special is like stepping back in time, where every gear shift and throttle tweak unleashes a rich symphony of power and character that refuses to be tamed.
Key Specifications
Engine Type
Four stroke, V-Twin, Twin Cam 103B Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, two valves per cylinder, with Integrated Oil-Cooler
Engine Capacity
1690 cc / 103.1 cub in.
Max Torque
132 Nm / 13.4 kgf-m / 98.2 ft. lbs @ 3250 rpm
Fuel Tank Capacity
18.9 Litres / US 5.0 gal
Weight (Wet/Kerb)
734 lbs / 333 kg
Seat Height
26.4 inches / 670 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Harley Davidson Softail Fat Boy Special
Year
2016
Engine
Engine Type
Four stroke, V-Twin, Twin Cam 103B Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, two valves per cylinder, with Integrated Oil-Cooler
Displacement
1690 cc / 103.1 cub in.
Bore x Stroke
98.4 x 111.1 mm
Compression Ratio
9.6:1
Max Torque
132 Nm / 13.4 kgf-m / 98.2 ft. lbs @ 3250 rpm
Engine Management System
Electronic Sequential Port Fuel Injection (ESPFI)
Cooling System
Air cooled
Exhaust
Denim Black and Satin Chrome, over/under shotgun exhaust with dual mufflers
